Ball Trough Switches
(Viewed from underside of playfield to show locations)
5070-06258-00 01-8652 5647-12073-00
Diode
Bracket
Microswitch
5647-09957-00
Microswitch
A-5844-44
Sw Wire
&
Brkt
0-11335-1
Item Part Number
Description
1 03-8053
Ball Popper Cap
2 A-11657
Switch Assembly
a) A-11658
Switch & Diode Assy
b) 01-3670-1
Switch Plate
c) 4205-01016-14
Wood Screw, #5 x
7/8
3 20-9314-7
Dowel Pin,
3/32
x 112
4 AE-24-900
Coil Assembly
5
A-13964
Bracket Assembly
6 10-135
Spring
7 A-11336
Armature Assembly
8 23-6420
Rubber Grommet
9
4008-01017-05
Mach. Screw, 8-32 x
5/16
10 B-11631
Ball Popper Bracket Assy
11 03-7067
Coil Tubing
8
~----
A-8645
Sw Wire & Brkt
5070-06258-00
Diode
5647-09957-00
Microswitch
RM-21-03
Tubing,
Ball Popper Assembly
2-19
Ball Trough
Sw
Ball Popper
