C-12842-1
Jumper Bumper Assembly
32
•
I
t=='
i
I
t=.d
I
21--+i
I----{
6
Item Part Number
Description
Item Part Number
Description
1 01-9117
Mounting Bracket
17 01-9116
Bracket, Bumper
2 B-12749
Core Plug & Bracket Assy
18 01-9320
Plate
3 03-8324-5
Base, White
19 02-3406-1
Plunger Coil
4 03-6035-7
Wafer, Black
20 01-9319
. Bracket Plunger
5 03-8292-7
Body, Black
21 4705-00002-00
Spring Washer, 1/2"
6 AE-23-800
Coil Assembly
22 4406-0111 9-00
Nut, 6-32 ESN
7 10-326
Compression Spring
23 H-12769-2
Cable, White
8
A-12854
BodylRing Assembly
24 H-12769-1
Cable, Red
9 4008-01070-14
Mach. Screw, 8-32 x
7/8
25 01-9321
Switch Plate.
10 4408-01119-00
Nut, 8-32 ESN
26 4005-01016-18B
Mach. Screw, 5-40 x
1-1/8
11 4008-01015-04
TT, 8-32 x
1/4
27 01-9166
Plate
,
. .
-
12 4008-01015-06
TT, 8-32 x
3/8
28 B-13267
Switch & Diode Assembly
13 4108-01001-10
Sh. Metal Screw, #8 x
5/8
29 03~7066
Coil Tubing
14 24-8768
Bulb #555 (6.3v., 0.25A.)
30 03-8291-13
Thumper Bumper Cap, Clear
15 24-8813
Lamp Socket
31 4004-01003-08
Mach. Screw, 4-40 x 1/2
16 10-411
Compression Spring
32 03-6047-16
Spacer, 1-1/16
2-17
Jet Bumper
