C-13174-R Right Flipper Assembly
Item Part Number
Description
Item Part Numbar
Description
1 B-13104-R
Flipper Base Assy, R.
21 B-10655-R
Crank Link Assembly, Right
2 03-7811
End of Stroke (EOS) Sw
a) 02-4179
Link Spacer Bushing
3 RM-21-06
Sleeve, Vinyl (Cap. leads)
b) 4010-01086-14
Cap Screw, 10-32 x
7/8,
SH
4 5045-12098-00
Capacitor, 2.2IlFd, 250V, 20% c)
4700-00023-00 .
Flatwasher,
5/8
x
13/64
x 16ga.
5 4701-00002-00
Lockwasher, #6 Split
d) 4701-00004-00
Lockwasher, #10 Split
6 4105-01019-10
Sh. Metal Screw,#5 x 5/8
e) 4410-01132-00
Nut, 10-32 ESNA
7 23-6622
Tape, Double-sided
f)
A-10656'
Flipper Link Assembly
8 4008-01079-05
Cap Screw, 8-32 x
5/16
1.) 02-4219
Coil Plunger
9 4701-00003-00
Lockwasher, #8 Split
2.) 20-9370-1
Spring Pin, 5132 dia. x
7/16
10 01-9375
Switch Mounting Bracket
3.) 03-8050-1
Flipper Link
11 03-7520-2
Ty-Wrap, Nylon
g)
B-10657-R
Flipper Crank Assy, R.
12 20-6516
Speednut, Tinnerman
1.) 01-8073-R
Flipper Crank, R.
13 4010-01066-06
Cap Screw, 10-32 x
3/8,
SH
2.) 17-1037
Crank Washer
14 4701-00004-00
Lockwasher, #10 Split
3.) 4010-01066-18
Cap Screw, 10-32 x
1-1/8
15 A-12111
Flipper Stop Assembly
4.) 4410-01127-00
Nut, 10-32 Hex Hd.
16 HW-30018-6
Wire, 18 AWG, Blue
5.) 4700-00107-00
Flatwasher,
5/8
x
13/64
x 12ga.
17 FL-11630
Flipper Coil (Red)
6.) 4701-00004-00
Lockwasher, #10 Split
18 01-7695
Solenoid Bracket
7.) RM-23-06
Tubing, H. S.
1/4
DWP
19 4006-01017 -04 Mach. Screw, 6-32 x
1/4
22 23-6577
Bumper Plug
20
10-376
Coil Plunger Spring
23 03-7568
Flipper Bushing
24 4006-01005-06
Mach. Screw, 6-32 x 3/8
25 4406-01117-00
Nut, 6-32 Hex.
, See Separate Diagram
Associated Parts:.
20-9250-6
Flipper Arm on Shaft (Yellow)
23-6519-4
Red Rubber Ring
Flipper
2·14
