Lamp Boards
B-12224 Single Lamp Board
C-13851 Ex-Ray Lamp Board
Part Number
Description
Part Number
Description
5768-12312-00
Lamp PCB
5768-12674-00
Lamp PCB
24-6767
Twist Lamp Socket
24-8767
Twist Lamp Socket
24-6766
Bulb #555, (6.3v, 0.25A.)
, 24-8766
Bulb #555, (6.3v, 0.25A.)
5070-09054-00
Diode, 1N4004, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A.
5791-10871-07
Connector, 7-pin Header Sq Post
C-13852 Dude Lamp Board
C-13853 Magnetic Lamp Board
Part Number
Description
Part Number
Description
5766-12675-00
Lamp PCB
5768-12676-00
Lamp PCB
24-8767
Twist Lamp Socket
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00
Diode, 1N4004, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A:
5791-10871-07
Connector, 7-pin Header Sq Post
5791-10871-05
Connector, 5-pin Header Sq Post
C~.t3854'
Refl'ex Lamp Board
C-13855 3-Lamp Board
Part Number
Descrlp,ion
Part Number
Description
5768-12677-00
Lamp PCB
5768-12678-00
, Lamp PCB
24-8767'
Twist LampSocket
24-8767
Twist Lamp Socket
24-8768
Bulb #555;'(6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00
Diode, 1N4004, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A.,:
5791-10871-08
Connector, 8-pin HsaderSq Post
5791-10871-05
Connector, 5-pin Header Sq Post
C-13911
"Jumper.
Lamp Board
C-13954 Back
P~nel
Part Number
Description
Part Number
Description
5768-12688-00
Lamp PCB
5768-12699-00
Lamp PCB,
24-8767
Twist Lamp Socket
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00
Diode, 1N4004, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A.
5791-10871-05
Connector, 5-pin Header Sq Post
5791-10871-06
Connector, 6-pin Header Sq Post
\
]
l
I
!
2·13
Lamp Boards
