A-15368-1
Eject Assembly
•
Q) Q)
Item Part No.
Description
1.
01-10652
Bracket
2.
23-6240
Rubber Grommet
3.
A-15371
Plunger Assembly
4.
10-135
Spring
5.
03-7067-5
Coil Tubing
6.
01-8-508-T
Solenoid Bracket
7.
4008-01017-04
Mach. Screw, 8-32 x
1/4"
8.
AE-30-2000
Coil Assembly
•
A-17241
Ramp Diverter Assembly
•
2-21
Item Part No.
1.
01-11957
2.
A-10821
3.
01-7695
4.
20-8790
5.
FL-11753-1
6.
4006-01017-04
7.
4010-01066-06
8.
4701-00004-00
9.
03-7066-5
10.
A-16636
11.
10-303
12.
A-14185
13.
4010-01169-04
Associated Parts:
(Not Shown)
14.
A-18977
15.
20-8712-25
16.
4700-00072-00
Description
Mounting Bracket
Flipper Stop Bracket
Solenoid Bracket
Nyliner Bearing
Flipper Coil Assy.
Mach. Screw, 6-32 x
1/4"
Mach. Screw, 10-32 x
3/8"
Lockwasher #10 Split
Coil Tubing
Diverter Plunger Assembly
Spring
Drive Arm Assembly
Set Screw, 10-32 x
1/4"
Diverter Flag Rivet Assy.
E-Ring,
1/4"
Shaft
Flatwasher,
17/64
x
1/2"
