B-9414-3
Jet Bumper Assembly
Item Part No.
1.
2.
3.
4.
5.
6.
7.
A-4754
03-6009-A5
03-6035-4
03-7443-5
10-7
24-8776
24-8768
Associated Part:
8.
03-8254-9
A-941 5-2
Jet Bumper Coil Assembly
2-20
Item Part No.
1.
2.
3.
4.
5.
6.
7.
8.
9.
B-7417
01-1747
01-5492
01-5493
02-3406-1
10-326
AE-26-1200
4006-01017-04
03-7066
Description
Bumper Ring Assembly
Bumper Base, White
Bumper Wafer, Red
Bumper Body, White
Spring
Socket-Wedge Base
Bulb #555 (6.3v., O.25A.)
Jet Bumper Cap
Description
Bracket & Stop Assembly
Coil Retaining Bracket
Armature Link, Steel
Armature Link, Bakelite
Coil Plunger
Armature Spring
Coil Assembly
Mach. Screw, 6-32 x
1/4'
Coil Tubing
•
