A-15849-L-2
Flipper Assembly
2
»<:
/'
<,
/'
<,
/'
»<;
<:>
/'
"-
/'
"-
/'
»<:
>;>
/'
"-
/'
»<:
/'
/'
/'
/'
/'
/'
/'
/'
Item Part No.
Description
Item Part No.
Description
1.
B-13104-L
Flipper Base Assembly, Left
18. A-15848-L
Crank Link Assembly, Left
2.
SW-1A-194
Switch Assembly
a) A-17050-L
Flipper Crank Assembly, Left
3.
4701-00002-00 Lockwasher, #6 Split
b) A-15847
Flipper Link Assembly
4.
4105-01019-10 Sh. Metal Screw, #5 x 5/8"
c) 02-4676
Link Spacer Bushing
5.
4008-01079-05 Mach. Screw, 8-32 x 5/16"
d) 4010-01086-14 Cap Screw, 10-32 x 7/8"
6.
4701-00003-00 Lockwasher #8 Split
e) 4700-00023-00 Flatwasher, 5/8 x 13/64 x 16ga.
7.
01-9375
Switch Mounting Bracket
f) 4701-00004-00 Lockwasher #10 Split
8.
20-6516
Speednut, Tinnerman
g) 4410-011 32-00 Nut, 10-32 ESN
9.
401 0-01 066-06 Cap Screw, 10-32 x 3/8"
19. 23-6577
Bumper Plug, 5/8"
10.
4701-00004-00 Lockwasher #10 Split
20. 03-7568
Flipper Bushing
11.
A-12390
Flipper Stop Assembly
12.
FL-11629
Flipper Coil, Blue
Associated Parts:
a) 03-7066-5
Coil Tubing
(Not Shown)
13.
01-7695
Solenoid Bracket
14.
4006-01 017-04 Mach. Screw, 6-32 x 1/4"
21. 23-6695
Flipper Rubber Ring, Red
15.
10-364
Spring
22. 20-9250-29
Flipper & Shaft
16.
4006-01005-06 Mach. Screw, 6-32 x 3/8"
17.
4406-01117 -00 Nut, 6-32 Hex
2-16
