A-18532
Motor Driver Master Board Assembly
c....
g
~
0-1:Bill-
LED1
Part No.
Designator
Description
Part No.
Designator
Description
.;
5040-12988-00 C1, C3
Cap., 10jJFd, 35v, Rad.
5010-09358-00 R1-R6, R8-R16 Res., 1K, 1/4w, 5%
5048-12036-00 C2,C4,C10
Cap., 0.22jJFd, 50v, Ax.
501 0-09001-00 R7
Res., 330, 1/4w, 5%
5043-08996-00 C5-C8
Cap., 0.1jJFd, 50v, Ax.
5010-09034-00 R17
Res., 10K, 1/4w, 5%
5040-09421-00 C9
Cap., 100jJFd, 25v, Rad.
5010-09356-00 R18
Res., 820, 1/4w, 5%
5281-09486-00 U1
IC, 74LS374, Oct. Latch
5791-10850-00 J1, J3
Connector, 26-pin Header
5281-10043-00 U2
IC, 74LS175, Quad FF
5791-10862-05 J2
Connector, 5-pin Header
5162-12422-00 U3,U4
IC, ULN2603, Array Drv
5671-13732-00 LED1
LED Display Red
5460-12423-00 U5
Reg, 7812,+12v
•
A-19141
Opto Board Assembly
~
~
1EJ3
OPT01
4
2
5
8
1
CII
g~
5
(
II
---fR2l-
~
18
3
OPT02
4
2
5
ffi
4
3
1
8
Hem Part Number
Designator
Description
1.
A-18822
Opto Track Encoder PCB
5791-13830-06
J1
Connector, 6-pin Header
5010-09061-00
R1, R2
Res., 680n, 1/2w, 5%
5070-08919-00
01,04
Diode, 1N4004, 1.0A.
5490-14327-00
OPT01, OPT02
Opto Integrated, 10mA.
•
5160-10269-00
Q1, Q2
Trans., 2N3904, NPN
5010-08998-00
R3, R4
Res., 2.2K, 1/4w, 5%
5043-08996-00
C1
Cap., 0.1jJFd, 50v, Ax.
2.
01-13160
Bracket
3.
07-6688-18
Rivet, 3/16 x 1/8"
4.
4700-00003-00
Flatwasher, 1/8 x 9/32 x 21gao
2-15
