Backbox Assembly
I
r-----------j
11
• Ribbon Cables
Item Part No.
Description
Item Part No.
Description
1.
01-6645
Venting Screen
17. 5795-12653-03
Ribbon Cable, 3"
2.
B-1 0686-1
Knocker Assembly
18. 5795-13018-01
Ribbon Cable, 23.5"
3.
A-12497
Insert Bd.Hinge Assy., Upr.
19. 5795-10938-15
Ribbon Cable, 15"
4.
A-14092-5
WPC Mounting Plate Assy.
20.
5795-12838-30
Ribbon Cable, 30"
5.
A-12498
Insert Bd. Hinge Assy., Lwr.
21.
5795-10938-32
Ribbon Cable, 32"
6.
A-12697-3
Power Driver Assembly
22.
5795-14325-00
Ribbon Cable,V-8 Mtr.
7.
A-16917-50036
Sound Board Assembly
8.
A-1 7651-50036 WPC Security CPU Board
9.
A-17814-50036A Backbox, Screened
• Miscellaneous Parts
10.
01-9047
Insert Stop Bracket
11.
A-18614
Speaker/Display Assembly
A-8552-50036
Tempered Backglass Assy.
12.
A-14039.1
Dot Matrix Controller Board
03-8228-2
Glass Channel Top (1)
13.
A-13379
Lock & Plate Assem bly
03-8228-3
Glass Channel Edge (2)
14.
50036-IN
Insert Board
03-8229-1
Glass Lift Channel (1)
15.
A-15472-1
Fliptronic II Board
08-7456
Backbox Glass:27x18-7/8"
16.
A-18532
Motor Driver Master PCB Assy.
31-1357 -50036 Screened Translight
