12. Install playfield mylars if desired.
NOTE:
The
CORVETTE
playfield has a special hardcoat surface and does not require a full
protective mylar. However, mylars can be purchased through your local Bally Distributor. Specify
part number 03-9295-1 for full playfield mylar.
13. Clean and reinstall the playfield cover glass, reversing the procedure of step 7.
14. To attach line cord, remove envelope stapled to the inside cabinet (near cashbox). Remove the four
Phillips-head screws that mount the line cord cover plate to the rear cabinet. Match the prongs on
the plug with the holes in the receptacle and push line cord securely into place. Make sure cord
aligns with the indentation of plate (indentation should point toward bottom of cabinet). Remount line
cord cover plate. If desired, tamper resistant screws are provided in an envelope marked "Security
Screws" (located in cashbox) to remount cover plate.
(Part
of cabinet
shown
for reference only)
~
Receptacle
"...r-
.
"
<, ......••.....••...••.
_
Line Cord
&
Plug
1-4
