#867 - "CAMELOT"
INSTALLATION AND GENERAL OPERATION INSTRUCTIONS
On all games there are certain items that should be checked after shipment.
These are visual inspections which may avoid time consuming service work later.
Minor troubles caused by abusive handling in shipment are unavoidable. Cable
plugs and sockets may be loosened, switches (especially tilt switches) may go out
of adjustment. Plumb bob tilt switch should always be adjusted after game is set
on location and leg levelers are adjusted.
Visual Inspections before plugging in line cord: -
1. Check that all cable plugs are firmly seated in proper sockets.
2. Check that cables are clear of all moving parts and relays.
3. Check for any wires that may have become disconnected.
4. Check switches for loose solder or other foreign material that may
have come loose in shipment and could cause shorting of contacts.
5. Check wires on relay coils for proper soldering, especially the bare
(common) wire connecting a row of relay coils. Cold solder connections
may not show up in factory inspection, but vibration in shipment may
break contact.
6. Check that fuses are firmly seated and making good contact.
7. Check (manually) the stepping and resetting of all step-up units.
The wiper action should not be sluggish.
8. Check transformer for any foreign material shorting across wiring lugs.
9. Check w~r~ng transformer to correspond to location voltage.
(Transformer wiring card in front cabinet).
Before line cord is plugged in:
Check all plugs and sockets and dress cables:
(A)
Plugs in correct sockets.
(B) Plugs securely seated in sockets.
(C) Dress cables away from relays.
Check adjustment of the three (normally open) tilt switches:
(A)
Panel tilt on bottom of playfield panel.
(B) Plumb-bob tilt on left side of cabinet near front door.
(C) Ball tilt above plumb-bob tilt.
Insert one of the two balls into ball tilt assembly and adjust
bracket so ball will rollover switch blade if front of cabinet
is raised.
Plug in line cord:
Check adjustment of the three (normally closed) anti-cheat switches that
hold in anti-cheat relay:
(A)
On front door.
(B) On bottom of cabinet to right of cash box.
(C) On mounting board, near cable plugs.
NOTE: Adjustment of above switches should be checked after game is plugged
in. \If not properly adjusted fhe anti cheat relay may drop out
during normal playing of game.
