NOTES: 1.
Heat sink compound must be applied between transistor and heat sink.
2. Observe index mark on integrated circuit, polarity of capacitors and
diodes, and position of transistors.
3. The view of Q5 and its related heat sink and hardware is from the
bottom of the heatsink, to clarify installation.
Power Supply
pIn 0-8345-566
Item Part No.
Ckt Designator
Descrlpt!on
Item Part No.
Ckt Designator
Description
1 5765-09466-01
Bare P. C. Board
26 5164-12154-00 01
Transistor, MJEl5030, NPN
2 5013-09426-00 R7
Resistor, 2.15K, 1%, 1/4w, C. F. 27 5164-09056-00 04
Transistor, MPSD02. NPN
3 5013-09427-00 R8
Resistor, 4.991<,1%, 1/4w, C. F. 28 5194-12155-00 03
Transistor, MJEl5031, PNP
4 5010-09428-00 Ru
Resistor, 1.5K, 2%, 1/4w, C. F.
29 5194-09055-00 02
Transistor, MPSD52, PNP
5 5010-09085-00 Rl0
Resistor, 1.5K, 5%,l/4w, C. F.
30 5791-10862-15 3.16
Connector, 15 pin (Hdr)
6 5010-09541-00 R9
Resistor, 2.7K, 2%,l/4w, C. F.
31 5791-10862-06 3.15
Connector, 6 pin (Hdr)
7 5010-09508-00 R12
Resistor, 2700, 2%, 1/4w, C. F. 32 5791-09068-00 3.11
Connector, 12 pin (Hdr)
8 5012-09429-00 R13
Resistor, 0.120, 5%,5w
33 5321-09178-00
Fuseholder
9 5010-09536-00 Rl,R4
Resistor, 39K, 5%,1w
34 5731-08761-00 Fl
Fuse, 1/4A, 250v, S-B
10 5010-09061-00 R2,R5
Resistor, 6800, 2w
35 B-8416
05 Regr
Transistor/Heat sink subassy
11 50 10-09069-00 R3,R6
Resistor, 330K, 5%,1I2w, C. F.
a) 5162-09425-00 05
Transistor, 2N6057. NPN
12 5040-09419-00 Cl0
Capacnor, 18,000 mId, electr,
b) 5700-09445-00
Socket
2OV,axial
c) 5701-09652-00
Mica Insulator
'.
13 5040-09420-00 C9
Capacnor, 1000 mId, electr,
d) 5705-09431-00
Heatsink
25v, axial or radial
e) 4006-01003-12
Mach. Screw 5-32 x 3/4
14 5040-09423-00 C12
Capacnor, 330 mId, electr,
f) HW-30118-4
Wire, 18AWG, VEL, 4-3/8"
10v,radial
g) HW-30118-5
Wire, 18AWG, GRN,
4-318"
15 5043-09065-00 C15
Capacnor, 470 pld
h) HW-30118-9
Wire, 18AWG, WHT, 4-3/8"
16 5040-09053-00 Cl,C3
Capacnor, 100 mId, electr, 150V 36 5824-09428-00 TP2 - TP4
Terminal, #1502-1 (Test Post)
17 5043-09072-00 C2,C4
Capacnor, 0.1 mId, 500v, disc 37 5100-09418-00 BRl
Bridge Rectnier, 35A, 100V
18 5043-09446-00 C14
Capacnor, 0.1 mId, 5Ov, disc
38 5705-09042-00
Heat Sink
19 5040-09421-00 C7
capacnor, 100 mId, 25v, radial
39 03-7947
Tie Wrap
20 5040-09422-00 C8
Capacnor, 47 mId, 50v, radial
40 4005-01016-07
Mach. Screw, 5-40 x 7/16, RH
21 5070-06258-00 01,05,06
Diode, 1N4001
41 4700-00004-00
Flat washer, 318od x .146 id x 21 ga
22 5070-09054-00 03,04
Diode,lN4004
42 4701-00023-00
Lockwasher, #5, split
23 5075-09059-00 ZRl,ZR3
Zener, 1N5990, 3.9v, 5% 43 4405-01117-00
Hex Nut, 5-40
24 5075-09060-00 ZR2,ZR4
Zener, lN4764, 100v, 5% 44 20-9229
Heatsink Thermal Compound
25 5460-09424-00 ICl
Ie, Volt. Reg., MC1723C
45 5731-09342-00 FS,F5
Fuse, 7A, 250V, SoB
