Alphanumeric Master Display Board
pIn 0-10877
a
f~b
/}j\Je
d
()
Alphanumeric
Character
Part No.
Ckt Designation
Description
5760-10875-00
Bare P. C. Board
5791-10850-00 J8,Jl0,J12
Connector, 26 pin (Hdr)
5791-09437-00 J4,J6,J7
Connector, 20 pin (Hdr)
5791-10862-12 Jl
Connector, 12 pin (Hdr)
5791-10862-09 J2,J3
Connector, 9 pin (Hdr)
5791-10862-06 Jll
Connector, 6 pin (Hdr)
5010-10258-00 R2S, R26, RSO - R61 Resistor,l
M, 1/4 w, 5%
5010-08773-00 Rl, R2, R6, Rl0, R14, Resistor, 22 K, 1/4 w, 5%
R34, R35
5010-08772-00 R49
Resistor, 15 K,
1/4w, 5%
SO10-08981-00 R18 - R24, R27 - R33, Resistor, 10 K,
1/4
w, 5%
R36, R37, R39, R40,
R42- R48
5010-09534-00 Wl-W8
Resistor, 0
n
5010-10927-00 R3 - RS, R7 - R9, R38 Resistor, 8.2 K. 1/2 w,S%
Rll- R13, R1S- R17
5019-10387-00 SR1-SR3
SIP, 18 K, 9R, lOP, 5%
5043-08980-00 B
Capacitor, 0.01 !-lId, SOV
507S-09135-00 D1
Zener, 1N4740A, 10V, 1
W
5310-09153-00 U10,U11,U15-U18
IC, Hex Buffer, 4050
5310-09882-00 U3, U4, U7, U8
IC, Quad NOR, 4001B
5680-08969-00 U9, U12 - U14
IC, Cathode Seg. Driver,
UDN7180A
5680-08968-00 Ul, U2, U5, U6
IC, Anode/Digit Driver,
UDN6118A or 6184
a
Display Characters
Segment Designations
Marquee Score Display
&
Lamps PC Board
pIn 0-12146
Part No.
Description
Part No.
Description
D-l0877*
D-12145
20-9S66
Master Display PC Board
Mounted Displays Subassembly
PC Bd Support
24-8767
24-8768
03-8069-2
Socket, Twist Lamp (#555)
Bulb, #555 (6.3v, 6.2SA)
Double Ught Shield
