Page 548 - BallyMidway GREY Parts Catalog 16-9562-A

Micro Switches and Associated Assemblies - cont'd
Switch Used on Indy500 World Shadw ICofvet Addam Magic Who?
Part Number Assembly Part No. 50026 50031 50032 . 50036 50038 50039 50044
Game and Pan Quantity
5647-09957-00 8-8925 Micro Sw Plate Ass'y I 2
(See p. 4-18)
5647-12133-08 *A-17995 Spin Tgt Switch Ass'y I
(See p. 6-14) 1
5647-12133-11 A-9381-R Eject Switch Ass'y I 1
(See p. 6-13) !
A-17985-l Eject Switch Ass'y I 1
I
A-17965-R Eject Switch Ass'y 1 3 1 1 1
(See p. 6-13)
5647-12133-12 A-10415 SwitchlTerm Strip Ass'y I 1
(See p. 6-13)
5647-12133-16 A-16536 Gun Assembly 1 I
(See p. 5-80)
·Used in conjunction with Spin TargetA-18199 (see p. 4-29).
5647-12133-06 5647-12133-16
6-6 (jJ~/MIDWAY
