Ball Gate and Switch Gate Assemblies ~cont'd
WORLD CUP (50031)
Part Number
A-8244~L
01-6935
01-6938~1
12-6882~1
A~10744
01~8119
12-6662
Description
Ball Gate Assembly
Ball Gate
Mounting Bracket
Gate Hinge Pin
Ball Gate Assembly
Mounting Bracket
Ball Gate Wireform
Quantity
Per Game
1
1
A~17797-1
01-6935
01~12347
12-6657~L
12-6882~1
Ball Gate Assembly
Ball Gate
Mounting Bracket
Ball Gate Wireform
Gate Hinge Pin
1
A~18385
C-12709
H-18608
01-8240
01-8600
01-13031
03-8022-5
03-8063-4
03-8063-6
07-6688-18N
12-6938
*31-1925-23
4002-01105-08
4006-01003-14
4406..Q1119-00
5070-09054-00
5647-12693-11
*Not available individually.
See p. 7-15a for sets.
Jackpot Board Assembly
3-Lamp PCB Ass'y
SwitchfLamp Cable Ass'y
Nut Plate #2-56
Insulator
Mounting Bracket
Spacer, .343 (2)
Bulb Sleeve, Red
Bulb Sleeve, Yellow (2)
Rivet
1/8
d. x
3/16 (2)
Switch Gate Wireform
Playfield Plastic
MS #2-56 x
1/2
P-PH-S (2)
MS #6-32 x
7/8
P-PH-S (2)
Nut #6-32 ESN (2)
Diode 1N4004 1.0A
Mini Micro Switch
2
4-16b
