Page 187 - BallyMidway GREY Parts Catalog 16-9562-A

Mounted Under Bottom Arch Assembly:
15 01-13593 Ball Guide
Ramp and Trough Locations
Mounted Under Playfield:
D A-19963 Ball Trough Assembly
Ball Guides
Item Part Number
1 A·13204-50026
2 03·9216-13
3 01·13842
4 01-13843
5 01·14002
6 01-13912.1
7 04-10203
8 A·20180
9 04-10202
10 01·14089
11 01-14088
12 04·10044
13 01-13840
14 04·10058
Item Part Number
A A-19980
B A·19979
C A·20410
(50026)
Ball Guide and Ramp Locations
Description
Bottom Arch Assembly
Flipper Ball Guide (4)
Ball Guide
Ball Guide
Ball Guide
Ball Guide
Ball Guide Assembly
Ball Stop Assembly
Ball Guide Assembly
Kicker Ball Guide, Right
Kicker Ball Guide, Left
Ball Guide Assembly
Ball Guide
Ball Guide Assembly
Description
Pit Ramp Assembly
Serpintine Ramp Assembly
Shooter Ramp Assembly
(jJafPLt /MIDWAY 3·7b
