Page 125 - 77_78_WMS_PARTS_ASPIRE

0-7251
3" DRUM UNIT ASSEMBLY
WITHOUT PRINTED CIRCUIT AND CONTACT RING
(FOR OJO,lOo,ANDIOOO SCORES)
20A-8712 -25
3C-7272 --"'\.
38-729
NOTE: ON 1000
SCORE UNITS USE
PART NUMBER
SW·IM-20S
BI-29
1600
e
18 -5155
LUBRICATION:
DO NOT PUT LUBRICANT ON DRIVE ARMATURE .
PROPER LUBRICATION WILL INSURE A LONGER LASTING AND BETTER
OPERATING UNIT .
POINTS TO BE LUBRICATED ARE THE THREE POSTS ON WHICH THE NYLON
PARTS ROTATE. EACH TOOTH OF' THE RATCHET, AL.SO RATCHET CAM AND
TOP OF' DRIVE PAWL· SRACKE T, INDICATED 9 Y *
" SERVICE SUGG ES nON."
IF usrr BECOMES SLUG GfSH - DISASSEMBLE. CL.EAN ALL PARTS , AND
R'EASSEMBLE. LUBRICATING ALL PARTS MARKED VlIT'H *
120
