For those of you, who are new to the maintenance of the slug rejectors, we suggest
that the following points be observed:
A slug rejector is never oUed.
Every slug rejector bas one or more permanent magnets whi .chtend to pick
up steel filings. A spare unit should. therefore, be wrapped or bagged.
In case of difficulty, first make certain that you have the proper instructions
for your particular rejector and then follow the instructions step by step.
In the event of a malfunction of the slug rejector. proceed as follows :
1. Remove the rejector from your coin operated machine.
2. Open the scavenger (it hinges to the left) and inspect for cleanliness. If
there is the least doubt as to its being clean, follow the eleantng .pzoce-
dure on the enclosed single sheet.
3. Check all screws for tightness.
4. Stand rejector upright on level surface and insert quarters. Observe to
see whether quarters .accept. reject or ~ in rejector. The accept and
reject chutes are as shownbelow:
Reject
Chutes
Accept
Chute
BOTTOMVIEW
5. If quarters accept during above test, follow this procedure:
A. Push operatLng lever downand release slowly. Retest. If quarters
are now rejected, follow instructions in paragraph #6.
B. If quarters are accepted, replace rejector in machine. Check for
mechanica lbinds or interference from some part of the machine.
An improper lyleveled machine can cause rejection of genuine quar-
ters.
6. If quarters reject during the test:
A. Push operating lever downand release slowly. If lever does not re-
turn to normal. quarters will be rejected. In this event, check for
binds or weak operating lever spring.
