Page 98 - 1987_BALLY_ASPIRE

TOP PLAYFIElD ASSEMBLY WIO PLASTICS - PARTS LIST
PART NO. AHOI-OOOO4-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 A360-00234-0000 KICKER ASSY.: TOP MOUNTED. BAL RETURN (SEE PAGE 8)
A365-00339-0300 SWITCH-TO-TROUGH COVER ASSY.-3 BALL (INCLUDES ITEMS 2 THRU 5)
2 AHOI-00033-0000 WIRE-TO-SWITCH ASSY. (3 REQ'D.)
0017-00007-0015 NUT: 1/8" PUSH (3 REQ'O.)
0017-00032-0123 SWITCH: MICRO; LOW-TORQUE (3 REQ'D.)
0365-00970-0003 WIRE-FORM: MICRO-SWITCH (3 REQ'D.)
3 A365-00349-0300 JUMPER CABLE BALL CONTROL ASSY.
4 OH01-00111-00XF BRKT.: BALL TROUGH COVER
5 OHOI-00913-0000 INSULATOR: MICRO-SWITCH
6 AA17-00023-0000 BALL REBOUND ASSY. (INCLUDES FOLLOWING 4 ITEMS)
OA17-00104- 0XF PLATE: REBOUND
OA17-00105-00XF WASHER: REBOUND (2 REQ'D.)
OO12-00010-37XF BUSHING: STEEL 3/8"
0017-00041-0715 BUMPER: REBOUND; GUM RUBBER
7 AH01-00020-0000 SHOOTER-LANE ENTRANCE ASSY. (LOCATED UNDER BALL DROP RAt~P)
OH01-00103-0000 SCOOP: SHOOTER-LANE ENTRANCE
8 AHOI-00028-0000 MULTI-BALL KICKER ASSY.
AH01-00025-0000 FROG POP-UP ASSY. (INCLUDES ITEMS 9 & 10)
9 OH01-0010S-0000 RIVET: SEMI-TUBULAR, .120" OIA., .812" L., 7/32" HD. OIA.,OVAL HO. (2 REQ'O.)
10 AHOI-00I05-0000 BRACKET: POP-UP SUPPORT
AH01-00029-0000 JUKEBOX MTG. BRKT. & P.C. BOARD ASSY. (INCLUDES ITEMS 11 THRU 13)
11 AH01-00047-0000 JUKEBOX P.C. BOARD W/LAMP & SOCKET ASSY.
AE14-00039-0000 LAMP W/SOCKET ASSY.
