TOP PLAYFIELD 'ASSEMBLY W/PLASTICS - PART LIST, CONTID ..
PART NO. AE79-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
0967-00108-0000 BRKT. : GATE
8 AE79-00033-0200 THUMPER-CAP W/HOT-STAMP ASSY. (VERTICAL MTG.) (2 REQ'D.)
9 AE79-00021-0000 BALL SCOOP ASSY. UPPER LEFT
10 AE79-00022-0000 BALL SCOOP ASSY. UPPER RIGHT
11 AE79-00024-0000 TOP REAR PLATFORM ASY.: (SEE PAGE 46)
12 AE79-00023-0000 FLIPPER PLATFORM ASSY.: (SEE PAGE 50)
13 AE79-00030-0000 ENTRANCE RAMP ASSY. (INCLUDES ITEMS 13 & 14)
14 0360-00022-0000 BALL GATE ASSY. (UNDER TOP REAR PLATFORM ASSY.)
15 OE52-00108-0000 PLATE~ RAMP ENTRANCE
16 OE79-00914-0000 RAMP: UPTOWN
-
17 A365-00312-0100 MOLDED FLIPPER - CAP ASSY. (WHITE) LEFT
18 A365-00312-0200 MOLDED FLIPPER - CAP ASSY. (WHITE) RIGHT
19 OE79-00117-00XF SHOOTER GAUGE
20 OE79-00912-00XF BOTTOM ARCH: SCREENED
21 OE79-00506-0000 BACKBOARD: PLAYFIELD
22 AE79-00033-0200 THUMPER-CAP W/HOT-STAMP ASSY. (450 MTG.)
23 SEE COMMON SOCKET ASSY. (SEE PAGE 34)
24 AE79-00031-0100 BALL STOP ASSY. RT. SIDE (UNDER TOP REAR PLATFORM ASSY.)
25 AE79-00031-0200 BALL STOP ASSY. LT. SIDE (UNDER TOP REAR PLATFORM ASSY.)
26 A391-00052-0100 FLIPPER & SHAFT ASSY.: LEFT (BLACK)
A360-00602-00XF KICKER ARM W/SHAFT ASSY.
0391-00051-0100 FLIPPER W/HOT STAMP: LEFT (BLACK)
0017-00041-0643 BUMPER: WHITE RUBBER (LO" 1.0. )
27 OEI4-00103-0000 BRKT. : GUSSET
5.3
