TOP PLAYFIELD ASSEMBLY W/O PLASTICS - PARTS LIST, CONT'D.
PART NO. AE35-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
34 0360-00732-00XF POST: BUMPER 10 X 7 WOOD SCREW (6 REQ'O.)
35 0360-00733-00XF POST: BUMPER (NICKEL) (24 REQ'D.l
36 0360-00738-01XF STUD: 6 X 1 - 11/16" (10 REQ'D.)
37 0365-00508-0006 RAIL: TOP, GENERIC 8-3/8"
38 SEE COt1MON SOCKET ASSY~ (SEE PAGE 28 )
39 0967-00707-01XF STUD: 6-32 X 1-11/1611 (6 REQ'D.)
40 AE35-00044-00XF REAR BALL CHANNEL & BRKT. ASSY.
41 AE35-00501-DOXF PLAYFIELD W/INSERTS: SCREENED & PIERCED
42 OE35-00118-00XF BALL RUNrlAY
43 AE35-00042-000D V-METER EXIT-SCOOP ASSY.
44 OE35-00126-0000- PLATE: ATOM-SMASHER FRONT ENTRANCE - - -
AE35-00013-0000 RAMP-STUD TO SWITCH ASSY. (INCLUDES ITEMS 45 s 46)
45 AE35-00014-00XF BALL RAMP ASSY.
46 AE35-00015-0000 SWITCH W/BRKT. ASSY.: RAMP (UNDER BALL RM4P ASSY.)
AA40-00020-0000 MICRO-SWITCH & WIRE-FORM ASSY.(5 REQ'D.)(INCLUDES NEXT 3 ITEMS)
0010-00295-0000 WIRE-FORM: SWITCH-RAMP (5 REQ'D.)
0017-00007-0015 NUT: 1/8 PUSH (5 REQ'O.)
0017-00032-0123 SWITCH: MICRO, LOW-TORQUE (5 REQ'D.)
47 OE35-00 115-0000 BRKT.: ATOM SMASHER WIRE SUPPORT
48 AE35-00035-0000 DRAIN-ASSEMBLY LEFT
49 AE35-00037-0000 ATO~1 SHASHER REAR ENTRANCE ASSY.
50 AE35-00038-0000 BUBBLE-BONUS ASSY.
51 AE35-00041-0000 LIGHT-SHIELD ASSY. (4 REQ'D.)
52 AE35-00059-00XF CLEAR-PLASTIC W/BUSHING
53 0017-00042-0414 SPACER 1.095", NYLON (6 REQ'D.)
54 AE35-00139-0000 BRKT. : BALL DEFLECTOR
55 OE35-00149-0000 BRKT. : VALLEY GUARD
4.8
