TOP PLAYFIELD ASSEMBLY W/O PlASTICS - PARTS LIST
PART NO. AE35-00004-0000
ORDER BY PART UUI.,BER ONLY
ITEM PART NO. DESCRIPTION
1 A360-00234-0000 KICKER ASSY.: TOP MOUNTED (SE PAGE 8)
AE35-00 28-0000 ATOM SMASHER MULTI-BAL ASSY. (INCLUDES ITEMS 2 THRU 5)
2 OE35-00112-00XF BRKT. : ATOM-SMASHER RAMP MTG. HSG.
3 OE35-00113-00XF BRKT. : ATOM-SMASHER BALL-STOP
4 OE35-00114-00XF BRKT. : ATOM-SMASHER RUNWAY
5 OE35-00127-0000 BRKT. : SWITCH, ATOM SMASHER, LOAD
6 AE35-00039-0000 EXIT-ASSY.: THUMPER BUMPER
7 AE35-00040- 000 V-METER RIGHT-ENTRANCE ASSY.
8 AE35-00020-0000 OFFSET GATE ASSY.
OE35-00128 .•0000 BRKT. : AfJT I-GRAV ITY GATE
OE35-00917-0000 WIRE FORM: ANTI ...GRAVITY GATE
0365-00168-000 WIRE FORM: SCORING GATE
0365-00969-0000 BUSHING: SPINNER ACTUATOR WIRE
9 AE35-00053-0000 GATE BRKT. & WIRE-FORM ASSY.
0010-00613-0001 WIRE FORM: GATE
0967-00108- 000 BRKT. : GATE
10 .AEI4-00025-0000 G.ATE BRKT. & WIRE-FORM ASSY.
0360-00048-0000 BRKT. : GATE
0365-00146-0000 WIRE-FORM: SPIN~JER TARGET
'0365-00969-0000 BUSHING
0360-00927-0000 WIRE-FORM: GATE
11 A390-00044-0000 BRKT. WjWIRE FORM ASSY. ROLLOVER, RT.
0010-00283-0000 WIRE-FORM: ROLOVER RIGHT
0360-00134-0000 BRKT. ROLOVER-HIRE: RIGHT
12 A390-00044-0100 BRKT.: W/WIRE FORM ASSY. ROLOVER, LT.
4 .6
