Page 39 - 1987_BALLY_ASPIRE

TOP PLAYFIELD ASSEMBLY WIO PlASTICS - PARTS LIST
PART NO. AE47-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 A360-00234-0000 TOP MTD. KICKER ASSY. (BALL RETURN) (SEE COMMON ASSY.)
2 AEI4-00013-0000 SPINNER GATE ASSY.
0017-00104-0084 WASHER: 075 - .250 - .062 FL-B NYLON
0360-00132-0000 BRKT.: GATE
0360-00926-0000 WIRE FORM: SPINNER TARGET
0365-00146-0000 WIRE FORM: GATE
3 OE47-00104-00XF BRKT.: BALL DEFLECTOR
4 OE47-00019-00XF SPACER: 1-7/8"
5 OE47-00020-00XF SPACER: 3-1/4"
6 AE47-00022-0000 BALL-GUIDE ASSY.
7 AE47-00031-0000 BALL-GUIDE ASSY.
8 AE47-00032-0000 BALL GUIDE ASSY.
9 AE47-00033-0000 BALL-EJECT ASSY. (SEE COMMON ASSY.)
10 AE47-00501-00XF PLAYFIELD & INSERTS SCREENED & PIERCED
11 AA40-00033-0000 WIRE GATE & BRKT. ASSY.
12 A331-00042-0000 WIRE ACTUATOR ASSY. LEFT
0360-00135-0000 BRKT.: ROLL-OVER WIRE, LEFT
0360-00929-0200 WIRE-FORM: ROLL-OVER, LEFT
13 A360-0021S-0000 WIRE-ACTUATOR ASSY.: ~IGHT (2 REQ'D.)
0360-00134-0000 BRKT.: ROLL-OVER WIRE, RIGHT
0360-00929-0100 WIRE-FORM: ROLL-OVER - RIGHT
14 AE47-00049-0000 WIRE ACTUATOR ASSY.: RIGHT
0360-00134-0000 BRKT.: ROLLOVER WIRE-RIGHT
