I UP PLAn 1l:.lU AS!;I:.MUlY "'PLA!; I U;!; - t'AMI ~ ll~ I, UJN I . U.
PART NO. AE47-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
13 AA40-00019-0000 BALL GATE ASSV.
OA40-00117-00XF GATE: BALL
OA40-00702-0000 PIN: BALL GUIDE
14 OE47-00112-0000 BRACKET: HELICOPTER, RIGHT
15 OE47-00113-0000 BRACKET: HELICOPTER~ LEFT
16 A370-00052-0000 BALL GATE WIRE ASSV.
0370-00116-0000 BRKT. : GATE
0370-00907-0000 WIRE-FORM: GATE
17 0370-00053-0000 GATE & -8RKT. ASSY.
0370-00116-0000 BRKT. : GATE
.
0370-00908-0000 WIRE-FORt-1:GATE
18 A967-00031-0100 MOLDED FLIPPER ASSY. : SLACK (2 REQ'O.)
19 0017-00041-0643 BUMPER: 1. D. ~ I" RUBBER (2 REQ I O. )
20 0017-00041-0653 FLIPPER - RUBBER: 3" YELLOW ( 2 REQ 10. )
21 OE47-00109-00XF BOTOM ARCH: SCREENED
22 0370-00918-0300 BOTTOM ARCH: EXTENSION
23 OE47-OOllO-OOXF BALL SHOOTER GAUGE
24 M051-00E47-A013 INSTRUCTION CARD: SPECIAL FORCE
25 MOSI-OOE47-A014 FEATURES CARD
26 0360-00923-0000 COVER: SCORE-CARD (2 REQ'D.l
27 0390-00908-0000 SHIELD: PROTECTIVE MYLAR
28 0391-00921-0000 SHIELD: PROTECTIVE MYLAR
29 0391-00920-0000 SHIELD: PROTECTIVE t-1YLAR
30 SEE cm·1MON SOCKET ASSY.
3.3
