BOTTOM PLAYFIELO ASSEMBLY - PARTS LIST
PART NO. AE14-(}()()()4_OOOO
ORDER BY PART NUMBER ONLY
ITEM PART NO. I DESCRI PTION
I
1 AC70-00022-0100 IFLIPPER ASSY. SINGLE SWITCH LEFT (SEE COMMON ASSY.)
A365-00045-0000 FLIPPER BREAK SWITCH ASSY.
2 AC70-00022-0200 FLIPPER ASSY. SINGLE SWITCH RIGHT (SE COMMON ASSY.)
A365-00045-0000 FLIPPER BREAK SWITCH ASSY.
3 AC70-00023-0200 FLIPPER ASSY. DOUBLE .sWITCH LEFT (SEE COMMON ASSY.)
A365-00045-0000 FLIPPER BREAK SWITCH ASSY.
A365-00046-0000 FLIPPER - SWITCH ASSY.
4 AC70-00023-0200 FLIPPER ASSY. DOUBLE SWITCH RIGHT (SEE COMMON ASSY.)
A365-00045-0000 FLIPPER BREAK SWITCH ASSY.
A365-00046-0000 FLIPPER - SWITCH ASSY.
5 AE14-00019-DOQO DROP TARGET ASSY: LEFT HAND. SINGLE (SEE COMMON ASSY.)
6 AEI4-00036-0000 "Gil RELAY & MTG. BRKT. ASSY.
AE14-00030-0 00 IIG'· RELAY & COIL ASSY. (SEE COMMON ASSY.)
7 AE34-00021-0000 FREE GATE RELAY ASSY. (SEE COMMON ASSY.)
8 A331-00035-0000 BALL EJECT HOLE (SAUCER) ASSY. (SEE COMMON ASSY.)
9 A360-00235-0000 KNOCKER ASSY. (SEE COMMON ASSY.)
10 A365-00083-0000 FRE GATE ASSY.: PARTIAL PLATE (SEE COMMON ASSY.)
11 A967-00053-0000 THUMPER BUMPER ASSY. (3 REQ'D.) (SEE COMMON ASSY.)
12 A967-00059-0000 SLINGSHOT KICKER ASSV. (2 REQ'D.) (SE COMMON ASSY.)
13 AEI4-00005-0000 PLAYFIELD CABLE ASSV.
14 A360-00217-0000 WIRE ACTUATOR ASSY.
0360-00135-0000 BRKT: ROLLOVER WIRE
0360-00931-0000 WIRE FORM: BALL RETURN
15 A360-00241-0000 SWITCH & DIODE ASSY.
1 . 1 0
