Page 116 - 1987_BALLY_ASPIRE

BOTTOM PlAYFIELD ASSEMBLY - PARTS LISTPART NO. AH03-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART ND. DESCRIPTION
1 AC70-00022-020a FLIPPER ASSY. SINGLE SW/LT. (SEE PAGE 22)
2 AC70-0D022-010a FLIPPER ASSY. SINGLE SW/RT. (SEE PAGE 24)
3 A365-00342-0100 EJECT HOLE ASSY. : LEFT (SEE PAGE 28)
4 A365-00341-0100 EJECT HOLE ASSY. : RIGHT (SEE PAGE 30)
5 AH03-00028-0000 BALL STOP & COIL ASSY. (SEE PAGE 26)
6 AHOI-00027-0000 KICKER ASSY. : MULTI-BALL (SEE PAGE 32)
7 A967-00053-0100 THUMPER Bur1PER ASSY. (3 REQ I D. ) (SEE PAGE 14)
8 A967-00059-0000 SLINGSHOT KICKER ASSY. (2 REQ'D.) (SEE PAGE 16)
9 A360-00235-0000 KNOCKER ASSY. 2-LUG (SEE PAGE 7)
10 AH03-00005-0000 PLAYFIELO CABLE ASSY.
11 A365-R0300-F002 TARGET W/SWITCH & BRKT. : (BLUE) LUG-RT.
A365-R0300-0002 TARGET W/SWITCH ASSY. : (BLUE)
A967-00076-0100 SWITCH ASSY. : TARGET
12 A365-R0300-FOO3 TARGET W/S~IITCH & BRKT. : (YELLOW) LUG-RT. (2 REQ '0.)
A365-R0300-0003 TARGET W/SHlTCH ASSY. : (YELLOW)
A967-00076-0100 SWITCH ASSY. : TARGET
13 A365-R0300-FOO5 TARGET W/SWITCH & BRKT. : (WHITE) LUG-RT.
A365-R0300-0005 TARGET W/SWITCH ASSY.: (WHITE)
A967-00076-0100 SWITCH ASSY. : TARGET
14 A365-R0300-FOO7 TARGET W/SWITCH s BRKT. : (ORANGE) LUG-RT.
~. A365-R0300-0007 TARGET W/S~HTCH ASSY. : (ORANGE)
A967-00076-0100 SWITCH ASSY. : TARGET
15 A331-00042-0000 BRKT. W/WIRE FOR~1 ASSY. ROLLOVER LT. (7 REQ'D.)
0360-00135-0000 BRKT. : ROLLOVER-\·JIRE , LT.
