TOP PLAYFIELO ASSEMBLY W/PlASTICS - PART LISTPART NO.• AH03-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AH03-00011-00XF SCREENED PLASTICS SET W/BUSHING
OH03-00901-00XF BUTYRATE: FORMED BOTTOM ARCH
OH03-00901-00XA BUTYRATE: SCREEN W/DIE-CUT
0017-00042-0745 LIGHT -DOME: PLASTIC; CLEAR (4 REO I D. )
0967-00710-00XF SPACER: BUSHING (6 REQ 'D. )
AH03-00009-0000 BACKBOARD ASSY. (INCLUDES ITEMS 2 THRU 9)
2 AH03-00011-00XF SCREENED PLASTICS SET W/BUSHING
3 AH03-00024-0000 BACKBOARD CABLE ASSY.
4 AH03-00502-0000 BACKBOARD: W/INSERTS
5 0017-00042-0748 LIGHT -DDt1E: PLASTIC; AMBtR (2 REO' D. )
- (SEE 34) '6 SEE COMMON SOCKET ASSY. PAGE
7 0017-00101-0017 6 X 1/211 SLOTTED HEX W/WASHER SCRE~l (12 REQ'D.) (NOT SHOWN)
8 0017-00101-0025 8 X 1/211 SLOTTED HEX W/WASHER SCREW (4 REO' D. ) (NOT SHOWf~)
9 0017 -00101-0117 8 X 5/8" PHILLIPS TRUSS SCREW (5 REQ'D. ) (NOT SHOWN)
10 AH03-00031-0000 BALL GATE s HOLD DOWN ASS¥.
AH03-00030-0000 HOLD-DOWN BRKT. ASSY.
0011-00002-0900 ROD: GATE-BRKT.
0360-00304-0000 BRKT. : GATE
11 A365-00337-0000 BALL GATE & BRKT. ASSY. : RIGHT
0011-00003-3900 ROD
0365-00200-00XF BRKT. : GATE & BALL
0365-00203-0000 BRKT. : GATE
12 AA40-00034-0000 GATE BRKT. & WIRE-FORM ASSY.
OA40-00909-0000 WIRE-FORM: GATE-BRKT.
8.2
