Page 103 - 1987_BALLY_ASPIRE

BOTTOM PLAYFIELD ASSEMBLY - PARTS LISTPART NO. AHOI-OOOO4-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AC70-00022-0100 FLIPPER ASSY. SINGLE SWIRl (SE PAGE 24)
2 AC70-00022-0200 FLIPPER ASSY. SINGLE SWILT (SEE PAGE 22)
3 AC70-00023-0200 FLIPPER ASSY. DOUBLE SW/LT (SEE PAGE 26 )
4 AHOI-OOOO5-0000 PLAYFIELD CABLE ASSY.
AHOI-00036-0000 PLAYFIELD: LIGHT-CABLE ASSY.
5 A365-00342-0100 EJECT HOLE ASSY. : LEFT (SEE PAGE 32)
6 A.365-00341-0200 EJECT HOLE ASSY. : RIGHT (SEE PAGE 34)
7 AHOI-00016-0000 DROP TARGET ASSY. : 3 IN-LINE (SEE PAGE 28 )
8 AHOI-00027-0000 KICKER.ASSY.: ~lULT I-BALL (SEE PAGE 36)
AHOI-00032-0000 TOP PLATFORM ASSY. (INCLUDES ITEM 9)
9 A365-00341-0100 EJECT HOLE ASSY. : RIGHT (SEE PAGE 34)
10 A365-00036-0000 SWITCH W/DIOOE & PLATE ASSY.
11 0017-00101-0025 8 X 1/2" SLOTTED HEX W/WASHER SCREW (3 REQ' D. )
12 A967-00053-0100 THUMPER BUMPER ASSY. ( 3 REQ'D.) (SEE PAGE 14)
13 A967-00059-0000 SLINGSHOT KICKER ASSY. (2 REQ'D.) (SEE PAGE 16)
14 A360-00235-0000 KNOCKER ASSY. 2-LUG (SEE PAGE 7)
15 A365-L0343-B111 TARGET W/SPECIAL MOUNTING BRKT. RED (INCLUDES FOLLOWI!~G 2 IlErlS)
0365-00171-02XF BRACKET: TARGET 2-BANK
I--- A365-R0300-0 111 TARGET, SWITCH, DIODE & CAP ASSY. : RED, LUG-RT (INCL. NEXT ITEM)
A365-R0300-0001 TARGET W/SWITCH ASSY. : RED LUG-RT
16 A365-R0307-Fl11 TARGET, SWITCH, BRKT. , DIODE & CAP: RED LUG-RT ( 2 REQ' D. )
A365-R0300-0001 TARGET W/SWITCH ASSY. : RED LUG-RT (3 REQ'D. )
