Page 100 - 1987_BALLY_ASPIRE

TOP PLAYFIELD ASSEMBLY W/O PLASTICS - PARTS LIST, CONT'D.
PART NO. AH01-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
30 0017-00041-0644 BU~~PER: 1.D. = 1-1/2" RUBBER (2 REQ'D.l
31 0017-00041-0645 BUMPER: 1.0. = 2" RUBBER (2 REO'D. )
32 0017-00041-0646 BUMPER: 1.O. = 2-1/211 RUBBER (3 REQ'O.)
33 0017-00041-0653 FLIPPER-UBBER: YELLOW 3" RUBBER (3 REO' D. )
34 0017-00041-0716 BUMPER: REBOUND; WHITE RUBBER
35 0017-00042-0586 POST: L = 1" BLUE (6 REQ'D.)
36 0017-00042-0594 POST: L = 1-3/16" BLUE (21 REQ' D. )
37 0360-00732-00XF POST: BUMPER, METAL-MINI 10/32 X 7/16" (WOOD SCREW) {2 REQ'D.}
38 0360-00733-00XF POST: BUMPER (NICKEL) (6 REQ'D.)
39 0365-00700-00XF POST: BUMPER METAL-MINI 10/32 x 7/16" (2 REQ'D. )
40 0360-00738-01XF STUD: 6 x 1 - 11/16" (16 REQ' D. )
41 0967-00707-01XF STUD: 6-32 x 1-11/16" (8 REQ' O. )
42 0017-00042-0348 NYLON SPACER (2 REQ'D.)
43 OHOI-00503-0000 RAIL: RIGHT SIDE
44 OHOI-00504-0000 RAIL: UPPER; LEFT (WOOD)
45 SEE COMON SOCKET ASSY. (SEE PAGE 38)
AHOI-00009-0000 BACKBOARD ASSY. (INCLUDES ITEMS 51 s 52)
46 OHOI-00113-0000 BRACKET: PLATFORM-MOUNTING; REAR
47 OH01-00114-0000 BRACKET: CORNER-BRACE
AHOI-00032-0000 TOP PLATFORM ASSY. (INCLUDES ITEM 48)
48 'OHOI-00112-00XF BRACKET: PLATFORM-MOUNTING; FRONT
