RUBBER PARTS
8
B
~~(';(10'
Dimensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
excessof one.
•
(0) .
0
A. R521-4
2-1/2" Dia.
(2)
B. R521-3
2" Dia.
(1)
0
C. R521-1
1" Dia.
(4)
D. R521-5
3" Dia.
(4)
:0
0
E. R406-3
Flipper
(2)
F. R243
5/16" Dia.
(9)
G. R521-2
1-1/2" Dia.
(1)
PANE L TOP PARTS
1. Arch Rail ...........
M-1774
2. Rail Post (2) .........
C-907
3. Rail Post Cap (2) ......
C-908
4. Bottom Arch .........
P·5871-55
5. Shooter Gauge. . . . . . . . P·6359-21
6. Ball Gate (L) .........
A-1475-10
.•.
7. Ball Gate (Rl. ........
A-1475-9
~
.
D
I
a
8. Screened Plastics ......
A-2890-121
I
I •
9. Clear Plastic .........
A-2890-122
,
10. Target Assem.........
AS·9S2·1128
0
,
,
11. Thumper Cap ........
A-37l3-12
I
12. Guide Wire (2) ........
M-121-62
,
13. Guide Wire (2) ........
M-121-18
I
14. Guide Wire ..........
M-121-43
0
0
\
15. Guide Wire ... _ ......
M-l2l-44
I
16. Guide Wire (2) ........
M-l21-53
0
-
0
0
",
17. Spinner Gate (L) ......
AS-2250-34
,
18. Spinner Gate (R) ......
AS-2250-35
I
0
0
,
19. Mini Post
&
Rubber (2) .. AS-2836
LII.
20. Drop Target Assy. (2) ...
AS-2795-10
0 0
21. Ball Gate Assem.......
AS-2250-1S
22. Rollover Wire (4) ......
AS-2806
0
23. Outhole Wire . . . . .
.
.
~
AS-2806-21
24. Flipper & Shaft (2) .....
AS-2214-24
0
CONS. - Conservative
MED. - Medium
13
0
13
LIB.
-Liberal
Indicates movable posts for
scoring adjustments.
23
,.
..
}.
..
,
/
WHEN ORDERING PART.
SPECIFY PART NO.
AND NAME OF GAME
