RETAINING RING
REJECT BUTTON_~n' P.2891.7
5-286·32 ~ COIN DROP
PLATE
PUSH BUTTON
ASSEMBLY
A·1729·17I
COIN DROP
CASTING
C·B28I FRONT DOOR EMBLEM
M-1895·Plain (Above)
M·1895·1 Susan B. Anthony (S.B.A.)
WINDOW &
PLATE BRACKET
P·7496
IN DROP
WINDOW
C·826
HINGE ASSEMBLY /
A-254-112 /
, ./ ,,0
30 S Q ~ 8
f I 32
C I I
I I
1 9 0 0 U
12
20 0 0
28
0
.
l.. <. EXTENSION SPRING
SP·l00-265
HINGE AS.SEMBLY <,
A·254·111 ~ TEST BUTTON
• MOUNTING BRACKET
P·6665-515
NUT & SCREW SUPPLIED
WHEN LOCK AND KEY
ISORDERED
0000
00000
000
°
o
°
o
°0
o
o
o
o
o 0
LOCK
M-2 Bl-22~
~
o 0 O LOCK SPACER
P-6264·86
PROTECTIVE SHIELD
UNDER SWITCH ASW-A2·73
M-1787·'
PUSH BUTTON
SWITCH
(CREDIT)
ASW-A10-46
PUSH BUnON
NUT & WASHER
-SUPPLIED
E·658-2
LOCK WASHER
M-1700·S
o
§
WHEN ORDERING PART.
SPECIFY PART NO.
AND NAME OF GAME
P·126-155
.•.•••.__ SWITCH GUARD
P·7716
40
RUBBER PARTS
Dimensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
excess of one.
A. R-521-' '" Dia. (4)
B. R·521·4 2-1/2" Dia. (5)
C. R·521-2 '·1/2" Dia.
D. R·521-3 2" Dia.
E. R-406-3 Flipper (2)
F. R-243 5/16" Dia. (12)
PANEL TOP PARTS
1. Arch Rail. M-1774
2. Rail' Post (2). . . . . . . .. C-907
3 . Rai' Post Cap (2) . . . . .. C-90S
4 . Bottom Arch P·5871-57
5. Shooter Gauge . . . . . .. P-6359·23
6. Ball Gate (L) A-1475-10
7. Ball Gate (R) A-1475-9
B. Plastic Covers (set) A·2890-137
9. Thumper Cap (3) , A·371344
10. Rollover Button (2) C-900
11. Plastic Guide (2) C-935-1
12. Target Assembly (2) . . .. ASE-2911-20
13. Outhole Kicker ASE-2694-3
14. R.O. Wire & Brk't. (7) .. ASE-2a06
15. R.D. Wire & Brk't ASE-2S06-26
16 . R.O. Wire & Brk't ASE-2806-'
17. Ball Guide Wire M-121-76
18. Ball GuideWire ' M-121-75
19. Ball Guide Wire M-121-24
20. Ball Guide Wire M·121·77
21. Ball Guide Wire (2) M-l.2.1-18
22. Ball Guide Wire M·12143
23. Ball Guide Wire M-12144
24. Buffer Wire (2) M-121·53
25. Flipper & Shaft Assy. (2) ASE·2214-24
26. Outhole Wire & Brk 't... ASE-2806-21
27. Minipost & Rubber (4) .. ASE-2836-1
28. Ball Guide Assy A-3032-33
29. Target Assy. (3) ASE·2911-27
30. Thumper Body (3) ASE-22224
31. Protective Angle. . . . .. P-7639
32. Hood P-1732
33. Panel CA-1128-165
WHEN ORDERING PARr.
SPECIFY PART NO.
AND lAME OF GAME
29
