Page 106 - Bally 1969 Parts Catalog

STEPPING UNITS, CONTINU__OU-S- --,
CONT ACT -PLA TE
(WIRED)
If Switch used, see Note A.
WIPER ASSY.
SEE NOTE A
o
~o
5-496-1
P-1158-6
SPRING-WASHER
(Not Visible)
Check unit manually by operating Plunger. After Index
Pawl drops into position at base of ratchet-tooth
(point at which straight and angular edges of tooth
meet), Step-up Arm should over-ride approximately
1/64 in. before being stopped by Step-up Arm Stop
("ear" formed in Base Plate). Bend Stop one way or
another to reduce or increase over-ride to approxi-
mately 1/64 in. Index Pawl should then properly drop
into base of tooth, without binding, when Plunger is
lightly operated (without pushing Plunger all the way
in). Adjust Stop-Plate against top of Step-up Arm so
that unit will step when Step-up Arm is operated
manually.
o
NOTE A
If Part Number not listed in SPECIFIC PARTS
DATA, commencing on page 8, order part by
name, specifying name of game, name of unit.
ALSO SEE STEPPING UNITS NOTE
ON PAGE 112
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
113
