Coin Door Assembly
A-14148-1
U.S.A. Door with Decals
09-17002-x
2-Chute Door
09-17003-x
3-Chute Door
("x" is the country designator)
Item Part No.
Description
Quantity
1
27-1038
Button Cover
20r3
2
27-1041-1-458 Price Panel
20r3
3
27-1026-1-4 17 Coin Entry Plate
20r3
4
27-1016
Lock Assembly
1
5
27-1061-1
Coin Return - Bezel
1
6
27-1062
Coin Return Flap
1
7
27-1021
Button Housing - 2-slot
1
~
27-1022
Button Housing - 3-slot
1
8
27-1111
Interlock Switch
1
9
27-1006-1
Coin Door, 2-Slot
1
27-1007-1
Coin Door, 3-Slot
1
10 27-1005
Coin Door Frame
1
11 27-1003
MIC Screw, 6-32 x
3/16
4
12 5641-12724-00 Diagnostic Switch
1
13 27-1101
MIC Screw, 4-40 x
1/4
2
14 01-9885
Bracket, Diagnostic Switch
1
15 27-1037
Plastic Button
1
16 27-1078
MIC Screw, 6-32 x
3/8
20r3
17 27-1039
Conical Spring
20r3
18 27-1079
Self-tapping Screw, #6 x
1/4
2
19 27-1077-1
Coinbox Cover
1
20 27-1066
Slam Switch
1
21 27-1067
MlC Screw, 4-40 x
1/2
2
22 27-1017
Nut (key)
1
23 27-1012
Locking Cam
1
24 27-1011
Locking Arm
2
25 27-1020
Washer
1
26 27-1018
Star Washer
1
27 27-1019
MIC Screw,
1/4-28
x
5/16
1
28 27-1089
R-Ring
1
29 27-1083
Retainer
1
30 27-1081
Coin Inlet Chute
2 or 3
31 27-1088
Cable Clamp
2or3
32 27-1025
Key Hook
1
33 27-1086
Washer, #6
2 or 3
34 27-1078
MIC Screw, 6-32 x
3/8
1 or 2
27-1113
MIC Screw, 6-32 x
7/16
1
35 27-1079
Self-tapping Screw, #6 x
1/4
2 or 3
36 27-1084
Lamp Socket
20r3
27-1085
Lamp
2or3
37 27-1096
Self-tapping Screw, #5 x
3/8
20r3
38 27-1087
MIC Screw, 6-32 x
5/8
2or3
39 27-1082
Lever Arm
2 or 3
40 27-1097
Switch Cover
2 or 3
41 27-1091-1
Coin Accept Chute
2or3
42 27-1075
Wire Form (Small)
2 or 3
or
27-1093
Wire Form (Large)
43 27-1094
MIC Screw, 4-40 x
7/8
4or6
44 27-1087
MIC Screw, 6-32 x
5/8
4or6
45 27-1086
Washer, #6
4 or 6
46 27-1095
Nut, 4-40 ESNA
4 or 6
47 27-1076-1
Coin Return Box
1
48 27-1078
MIC Screw, 6-32 x
3/8
2
49 27-1092
Microswitch
2 or 3
'---..._
WHITE WATER 2-34
