A-1S680 Bi-Directional Motor Drive Assembly
Part Number
5162-12635-00
5192-12428-00
5370-12272-00
5551-09822-00
5791-12273-04
5791-12273-05
5070-09054-00
5043-08996-00
5040-10974-00
5043-08980-00
5010-09085-00
5010-09034-00
5010-08991-00
5010-09061-00
5671-09019-00
Designator
01,03,05
02,04
U1
L1,L2
J2
J1
01 - 09
C1
C2
C3,B,C4
R2,R3,R9
R4,R5
R7, R8, R10, R11
R1, R6
LED1
Description
C\I
...,
fi]
..
Transistor TIP 102 NPN
Transistor TIP 107 PNP
I.C. LM339 Ouad Comp
Ind. 4.7)ill
Connector, 4-pin Header Str Sq. LCK .156
Connector, 5-pin Header Str Sq. LCK .156
Diode 1N4004, 1.0A.
Capacitor, 0.11lfd (±20%)
Capacitor, 100llfd, 35v (+80, -20%)
Capacitor, 0.011lfd, 50v (+1, -20%)
Resistor, 1.5Kn, 1/4w, 5%
Resistor, 1OKn, 1/4w, 5%
Resistor, 4.7Kn, 1/4w, 5%
Resistor, 680n, 1/2w, 5%
Display LED Red
WHITE WATER 2-16
