T.4 Solenoid Test
The Solenoid Test has three modes, Repeat, Stop, and Run.
Only one solenoid should pulse at a time. The system has detected a problem if; more then one
solenoid pulses, a solenoid comes On and stays On or, during the Repeat and Run mode, no
solenoid pulses.
Repeat
The Repeat mode pulses a single solenoid. After entering this test, Solenoid 1 shows in
the display and the corresponding solenoid activates. Press the Up or Down button to
cycle through the solenoids, one at a time. The same solenoid pulses until the Up or
Down button is pressed. Either press the Escape button to return to the Test Menu, or
press the Enter button to move to the next mode.
Stopped -
The Stopped mode halts the Solenoid Test. Press Enter during the Repeat mode and
the Solenoid Test stops. No solenoids should be activated while the test is stopped.
•
Either press the Escape button to return to the Test Menu, or the Enter button to move to
the next mode.
Running
The Running mode cycles through the solenoids automatically. The display shows the
name and number of the solenoid currently being pulsed.
T.5 Flasher Test
This tests the flashlamp part of the solenoid circuit exclusively.
This, like the Solenoid Test, has three modes: Repeat, Stop, and Run. During this test, only one
flash lamp circuit should pulse at a time. The system has detected a problem if more then one
circuit pulses, a circuit stays On or, during the Repeat and Run mode, no circuit pulses.
Repeat
The Repeat mode pulses a single flash lamp. After entering this test, the name and
number of the first flash lamp circuit shows in the display and the corresponding bulb(s)
flash. Press the Up or Down button to cycle through all of the flash lamps circuits one at a
time. The same circuit pulses until press the Up or Down button is pressed. Either press
the Escape button to return to the Test Menu, or press the Enter button to advance to
the next mode.
Stopped -
The Stopped mode halts the Flasher Test. No flash lamp circuit should be active during
this mode. Either press the Escape button to return to the Test Menu, or press the Enter
button to advance to the next mode.
Running
The Running mode cycles through the flash lamps automatically. The display shows the
name and number of the flash lamp circuit currently being pulsed, and the corresponding
bulb(s) flash.
T.6 General Illumination
This test checks all of the General Illumination circuits.
There are two modes of operation: Stop and Run.
Stopped -.
Press the Up or Down buttons to cycle through the General Illumination Test manually. All
illumination is tested first, followed by an individual circuit test. The circuit name and
number shows in the display while the corresponding lamps lights. If any other results
occur the system has detected an error.
Running
Press the Enter button any time during Stopped mode and the General Illumination. Test
cycles through automatically. For each circuit shown in the display the corresponding
bulbs should light. If any other results occurs the system has detected a problem.
WHITE WATER 1-14
