PINBALL GAME ASSEMBLY INSTRUCTIONS
WHITE WATER IS A 3 BALL GAME
Power:
Temp:
Domestic 120V @ 60Hz
Foreign 230V @ 50Hz
Japan 1OOV@ 50HZ
32°F to 100° F
(O°Cto 38°)C
Not to exceed 95% relative.
Dimensions: Width: 26" approx.
Depth: 56" approx.
Height: 85" approx.
Weight: 285 Ibs approx. (crated)
Hum Idlt v:
1. Remove all cartons, parts, and other items from the shipping container, and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts are
provided among the parts in the cash box.
3. Attach the front legs (after installing leg levelers), using leg bolts.
•
,..•...••
I I
I I /\
, I // \
I i-: »
//1 // «rr=r>: --I
\1' .> I
-:Jt:.- 1
Detail View· Leg Leveler
Appro. Playfield
Pitch Angle:
6·7 Degrees
;F ~
I I ~leg
leg leveler
Shaft
, -',
See Detail View : • . ' . .
Pinball Assembly, Playfield Pitei'" Angle, and Leg Leveler Details.
Nut --::::&;;:;;;;;;:".-- Foot Pad
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked or
pinched. Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position. Unlock the backbox, and remove the
backglass. Remove the shipping block holding the Insert Board. Unlatch and open the Insert Board.
Carefully lift up the Speaker Panel and lay it down on the playfield glass. (Be careful not to damage the Dot
Matrix Display/Driver.) This allows access to the bolt holes used for securing the backbox upright. To
secure the ba,ckbox, install the washer-head mounting bolts through the bottom holes of the backbox into
the threaded fasteners in the cabinet. Close and latch the Insert Board. Replace the Speaker Panel.
Reinstall the backglass, and lock the backbox.
..
'&'CAUTION
FAILURE TO INSTALL the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT a pinball game with the hinged backbox erect. Always lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or damage and
possible personal injury.
6. Extend each leg leveler slightly below the leg bottom, so that all four foot pads are extended about the
same distance. Remove the cabinet from its support and place it on the floor.
WHITE WATER 1·2
