Power Driver Board Interboard Wiring Continued ...
J116 -1
N/C
J116 - 2 Gray-Yellow (+12V) to Coin 000rJ2-4
J116 - 3 Black (Grd) to Coin Door J2-5
J116 - 4
N/C
J123 -1 NlC
J123 - 2 NlC
J123 - 3
N/C
J123 - 4 Blue-Orange (sol. 27 drive) to Chase lamp Brd Jl-5
J123 - 5 Blue-Yellow (sol. 28 drive) to Chase Lamp Brd Jl-S
J117 -1 NlC
J124 -1
N/C
J117 - 2 Gray-Yellow (+12V) to Dot Matrix Controller JSOS-7J124 - 2 NlC
J117 - 3 Black (Grd) to Dot Matrix Controller J606-3
J124 - 3
N/C
J117 - 4 Gray (+5V) to Dot Matrix Controller JS06-5
J124 - 4 NlC
J124 - 5 NlC
J118 -1
N/C
J118 - 2 Gray-Yellow (+12V) to Chase Lamp Brd Jl-7,
to 7-opto Switch Brd Jl-l, to 2-opto Switch Brd
J
r-s,
to Motor Drive Brd J 1-5
J118 - 3 Black (Grd) to Chase lamp Brd Jl-4,
to 7-opto Switch Brd Jl-3, to 2-opto Switch Brd
Jl-5, to Motor Drive Brd Jl-4
J118 - 4 NlC
J125
-1
Black-Brown (sol. 17 drive) to backbox flash lamp
J125 - 2 Black-Red (sol. 18drive) to backbox flashlamp
J125 - 3
N/C
J125 - 4
N/C
J125 - 5 Black-Yellow (sol. 20 drive) to backbox flashlamp
J125 - 6
N/C
J125 -7
N/C
J125 - 8
N/C
J125 - 9 Blue-Gray (sol. 24 drive) to backbox flashlamp
J119 -1 White-Violet (S.8VAC) G.I. to Coin Door Brd J2-2
J119 - 2
N/C
J119 - 3 Violet (return) G.I. to Coin Door Brd J2-1
J120 -1
J120 - 2
J120 - 3
J120 - 4
J120 - 5
J120 - 6
J120 -7
J120 - 8
J120 - 9
J120 -10
J120 -11
J121 -1
J121 - 2
J121 - 3
J121 - 4
J121 - 5
J121 - 6
J121 -7
J121 - 8
J121 - 9
J121 -10
J121 -11
Brown (return) G.I. to playfield
Orange (return) G.I. to playfleld
Yellow (return) G.I. to playfield
NlC
N/C
N/C
White-Brown (S.8VAC) to playfield
White-Orange (S.8VAC) to playfield
White-Yellow (S.8VAC) to playfield
N/C
NlC
J126 -1
J126 - 2
J126 - 3
J126 - 4
J126 - 5
J126 - 6
J126 -7
J126 - 8
J126 - 9
J126 -10
J126 -11
J126 -12
J126 -13
Black-Brown (sol. 17 drive) to playfield flash lamp
Black-Red (sol. 18 drive) to playfield flash lamp
Black-Orange (sol. 19 drive) to playfield flash lamp
Black-Yellow (sol. 20 drive) to playfield flashlamp
Blue-Green (sol. 21 drive) to playfield flashlamp
Blue-Black (sol. 22 drive) to playfield flash lamp
Blue-Violet (sol. 23 drive) to playfield flash lamp
Blue-Gray (sol. 24 drive) to playfield falshlamp
N/C
N/C
N/C
N/C
NlC
N/C
N/C
Yellow (return) G.I. to backbox
N/C
Green (return) G.I. to backbox
Violet (return) G.I. to backbox
N/C
N/C
White-Yellow (S.8VAC) to backbox
White-Green (S.8VAC) to backbox
White-Violet (S.8VAC) to backbox
J127 -1
N/C
J127·2 NlC
J127 - 3 Brown-Red (sol. 10 drive) to playfield coil
J127 - 4 Brown-Orange (sol. 11 drive) to playfield coil
J127 - 5 Brown-Yellow (sol. 12 drive) to playfield coil
J127·6 Brown-Green (sol. 13 drive) to playfield coil
J127 -7 Brown-Blue (sol. 14 drive) to playfield coil
J127 - 8
N/C
J127 - 9
N/C
J122 - 1 Blue-Brown (sol. 25 drive) to Motor Drive Brd Jl-2
J122 - 2 Blue-Red (sol. 2S drive) to Motor Drive Brd Jl-1 J128·1
N/C
J122 - 3
N/C
J128· 2
N/C
J122 - 4
N/C
J128· 3 Brown-Violet (sol. 15 drive) to backbox flashlamps
J122·5 NlC
J128 - 4
N/C
J122 • 6 NlC
J128 - 5 Brown-Gray (sol. lS drive) to backbox flash lamps
J122 -7 NlC
J122 - 8 NlC
J122·9 NlC
WHITE WATER
3-40
