A-1S680
Bi-directional Motor Board Assembly
o
o
*
o
o
...-
....,
J1 -
1 Blue-Red (sol. #26 driver) from Power Driver Board J122-2
J1 -
2 Blue-Brown (sol. #25 driver) from Power Driver Board J122-1
J1 -
3 Key
J1 -
4 Black (ground) from Power Driver Board J118-3
J1 -
5 Gray-Yellow (+12V) from Power Driver Board J118-2
o
*
o
o
J2 -
1 Red to Motor
J2-2Key
J2 -
3
N/C
J2 -
4 White to Motor
e
WHITE WATER 3-26
