Unique Parts List
Part Number
Description
Part Number
Description
A-11-574-PL
Playfield & Inserts
C-13317
Ball Guide Assy
A-11-927-574 Backbox Assembly
C-13318
Ball Guide Assy
A-12258-3
8-32 Stud Plate Assy
C-13321
Single Flashlamp Assy
A-13128-574
Carton Assembly
C-13332
Ball Guide Assy
A-13270
Bell Armature Assy
~!., ~
C-13334
Ball Guide Assy
A-13273-L
Ramp Sup Bracket Assy
C-13335
Ball Guide Assy
A-13273-R
Ramp Sup Bracket Assy
A-13274-L
Left Flipper Return Frame
D-11920-13
574-Mech Panel Assy
A-13274-R
Right Flipper Return Frame
D-13191
Wire Chute Assy
A-13278
Plunger Assembly
D-13199
Wheels Drive Assembly
A-13279
Drive Arm Assy
D-13356
Back Panel LampBd
A-13359
Ball Guide Assembly
D-13383
Ball Guide Assy
A-13360
Ball Guide Assembly
D-13384
Ball Guide Assy
A-13379
Lock Plate Assembly
A-13385
Ball Guide Assembly
R-13129
Left Ramp Assy
A-13415-L
Playfield Plastic Assy
R-13190
Right Ramp Assy
A-13415-R
Playfield Plastic Assy
A-13443
Stop Ball Eject Assy
01-9510
Plate-Post Adj #8
A-8552-574
Backglass Assembly
01-9511
Plate-Post Adj #8
A-8567-574
Domestic Cashbox Assy
01-9521
Ball Guide
B-13225
Cellar Kickback Assy
02-4252-32
Spacer,2
w
B-13233
Lifting Ramp Assembly
02-4334-14
Mounting Post, 3.25
B-13269
Bottom Arch Kicker Assy
02-4334-15
Mounting Post, 3.19
B-13276
Ramp Diverter Actuator
02-4335-12
Mounting Post, 1.38
B-13280
Diverter Arm
&
Shaft Assy
02-4418
Shaft
B-13289
3-Switch & Bracket Assy
02-4423
Bumper Post
B-13300
Switch
&
Bracket Assy
02-4424-1
Post, #6-32
1#8-32
B-13319
Ball Guide Assembly
02-4424-2
Post, #6-32
1#8-32
B-13320
Ball Guide Assembly
02-4425-1
Post, #8-32
1#8-32
B-13333
Ball Guide Assembly
02-4425-2
Post, #8-32
1#8-32
B-13339
Spinning Target Assy
02-4426-1
Post, #6-32
1
#8 SMS
B-13349
Left Cellar Loop
02-4429
Crank Pin
B-13350
Right Cellar Loop & Runway
02-4433
Post, #8 x
1-3/16
w
B-13351
R Ramp L Entry Ball Guide
02-4434
Post, #8 x 1
W
B-13377
Cellar Sign Bridge Assy
02-4435
Post, #8 x
1-3/16
B-13399
R Ramp R Entry Ball Guide
02-4436-1
F-F Spacer, 8-32 x 1
W
B-13416
Playfield Plastic Assy
02-4436-2
F-F Spacer, 8-32 x 2.31"
B-13417
Playfield Plastic Assy
02-4436-3
F-F Spacer, 8-32 x 2.69"
B-13418
Playfield Plastic Assy
02-4436-4
F-F Spacer, 8-32 x 3.12"
B-13419
Playfield Plastic Assy
B-13420
Playfield Plastic Assy
31-1002-574
Screened Playfield
B-13421
Playfield Plastic Assy
31-1006-574
Playfield Plastic Complete
B-13422
Playfield Plastic Assy
31-1006A-574 Playfield Plastic Sheet
B-13423
Playfield Plastic Assy
31-1008-574
Screened Bottom Arch
B-13424
Ramp Cover Assy
31-1009-574
Screened Shooter Plate
B-9414-3
Red Jet Bumper Assy
31-1357-574
Screened Backglass
31-1463-574
Drop Target Decal Set
C-13205-1
3-Bnk Opto Board
31-1536-574
Wheels Drive Decals
C-13281
6-Lamp PCB
31-1539-574
Ramp Decal Sheet (Top)
C-13282
8-LampPCB
31-1540-574
Ramp Decal Sheet (Bottom)
C-13283
6-Lamp PCB
C-13284-1
8-Lamp PCB
C-13287
Sound
OIL
Assembly
C-13310
Motor EMI Filter Assy
C-13311-R
1-Bnk Opto Board
C-13312-1
1-Bnk Drop Target Assy
