Ramp Lifting Mechanism
Ramp Lifting Mechanism Assembly
pin
8-11304
& Associated Parts
hem Part Number
Description
Item Part Number
Description
1 A-11137
Lift Crank Assembly
15 03-7066
Tubing, Coil
2 4406-01119-00 Nut, 6-32 ESN
16 4008-01021-07 Mach. Screw, 8-32 x 7/16
3 A-8050
Plunger Assembly, 2-1/4"
17 4701-00003-00 Lockwasher, #8 Split
4 4700-00073-00 Flatwasher, 9/32x1 /2x21 gao 18 4700-00089-00 Flatwasher,11/64x7/16x16ga.
5 12-6227
Hairpin Clip
19 B-11302
Lift Mech Bracket Assy
6 10-128
Spring
20 A-6892
Frame & Eyelet Assy
7 01-8-508-S
Coil Retaining Bracket
21 SM-26-600-DC Coil Assembly
8 4006-01017 -06 Mach. Screw, 6-32 x 3/8
22 A-11139
Armature Assembly
9 AE-26-1500
Coil Assembly
a) A-8936
Armature Sub-Assembly
10 B-7572-1
Bracket & Stop Assembly
b) 01-8390
Lift Crank Lock
11 4004-01003-10 Mach. Screw, 4-40 x 5/8
c) 4006-01003-03 Mach. Screw, 6-32 x
3116
12 5070-06258-00 Diode, 1N4001 , 1.0A.
23 10-363
Extension Spring
13 A-7438-1
Terminal Strip Assembly
24 12-6227
Hairpin Clip
14 5647-12001-00 Microswitch
