Flipper Assembly
Flipper Assembly Notes ...
Lower Left Flipper Assembly
pin
C-11626-L-3
(Parts listed replace same items of C-11626-R-3)
Item Part No.
Description
13 B-10655-L
Crank Link Assembly,
Left
g)
B-10657-L
Flipper Crank Assembly,
L
1.) 01-8073-L
Flipper Crank, Left
18 C-11627-L
Flipper Base Assembly,
L
1. Each Flipper Assembly on the Lower Playfield is mounted beneath the playfield, in conjunction
with the plastic Flipper Paddle and Shaft (20-9250-6) and flipper Rubber (23-6519-4) on the upper
side of the playfield.
2. The tip of the EOS Switch must travel 0.0150 (+ .010, - .000) inch, before the contacts fully open,
with the flipper in the actuated position. The EOS Switch contacts must have a gap of 0.062
(± .015) inch. Adjustment of the EOS Switch must be made at a minimum distance of 0.25 inch
from the switch body.
3.
All moving elements of the assembly must operate freely, with no evidence of binding.
4.
The large end of the Coil Plunger Spring (item 12) must fit within the four lugs of the Solenoid
Bracket.
5.
For coil replacement, remove the Solenoid Bracket (item 11) to prevent screw damage.
6. Use Loctite™ 242 when reattaching screws to the Flipper Stop Assembly, the Solenoid Bracket,
and the Flipper Bushing.
7.
When replacing ther Bumper Plug (Item 14) to restore proper flipper operation, readjust the flipper
paddle and shaft position.
8.
Solid color blue wire connects to the banded end of each diode, mounted on the connector end
of
the Flipper Coil (item 9). Trace color wire connects to the unbanded end
of
the diode.
13 f) 1.)
Flipper Link Assembly
pin
A-10656
[Items listed refer to items listed for C-11626-R-3]
Item Part No.
Description
13
f)
1.)
13
f) ,2.)
13
f)
3.)
02-4219
20-9370-1
03-8050-1
Coil Plunger
Spring Pin, 5/32 dia.
x
7/16
Flipper Link
