Lamp Boards
Lamp Board ("6-C")
pIn C-13281
Part Number
5768-12565-00
24-8767
24-8768
5070-09054-00
5791-10871-08
Description
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 8-pin sq post
Lamp Board ("8-R")
pIn C-13282
Part Number
5768-12566-00
24-8767
24-8768
5070-09054-00
5791-10871-10
Description
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 10-pin Sq post
Lamp Board (" 1")
pIn 8-12224
Part Number
5768-12312-00
24-8767
24-8768
5070-09054-00
Description
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Backbox Relay Board
(Solenoid 16 Gen. ilium)
pIn C-11 998-1
Part Number
5768-12243-00
5070-09054-00
5580-09555-01
5010-09534-00
5791-12273-02
5791-12273-07
Description
PC Board
Diode, 1N4004, 1.0A.
Relay, 24vdc, 30A.
Resistor,
on
Header, 2-pin Sq post
Header, 7-pin Sq post
(01)
(K1 )
(W1, W2) ,
(J1 )
(J2)
Lamp Board ("6-R")
pIn C-13283
Part Number
5768-12563-00
24-8767
24-8768
5070-09054-00
5791-10871-08
Description
Lamp PCB
Twist Lamp Socket
Bulb #555 (S.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 8-pin sq post
Lamp Board ("8-C"
+
"1-F")
pIn C-13284-1
Part Number
5768-12519-00
24-8767
24-8768
5070-09054-00
5791-10871-07
Description
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 7-pin Sq post
Playfield Relay Boards
(Solenoids 11 & 16 Gen. ilium)
pIn C-11902-1
Part Number
5768-12221-00
5070-09054-00
5580-12145-00
5791-12273-02
5791-12273-07
Description
PC Board
Diode, 1N4004, 1.0A.
Relay, 24vdc, 30A.
Header, 2-pin Sq post (J 1)
Header, 7-pin Sq post (J2) •
