• Parts Lists
&
Diagrams
Locations:
Game Circuit Boards and Major Mechanisms
Power Supply Board (0-12246)
Aux Power Oriver Board (0-12247-574)
Backbox Interconnect Board (0-12313-574)
Audio Board (0-111581-574)
System 11-B CPU Board (0-11883-574)
Master Oisplay Board (0-12232-1)
7-Segment Oisplay & Lamp Boards
All Major Mechanism Assemblies of
ww[}u~[faW~IJi)@]
Solenoids/Flashers
&
Rubber ·Parts
Switches
.-;
Lamps
Playfield Parts
