TEST/DIAGNOSTIC PROCEDURES (Continued)
AUTO BURN-IN MODE.
The Auto Burn-in Mode permits the operator to check intermittent (or nonrecurring) problems
associated with most portions of the game's circuitry. Repeatedly cycling through a group of tests
can sometimes bring a problem, which occurs only randomly or occasionally, to exhibit itseHmore
frequently, thereby aiding in the isolation of the problem. To activate the Auto Burn-in Mode:
1. While in the Game Adjustments, reach Ad 67 and change the Factory Setting of NO to YES, via
the Credit button. Set the AUTO-UP/MANUAL-DOWN switch to AUTO-UP.
2. Press ADVANCE to start the Auto Burn-in Mode. This mode repeatedly sequences through the
Music Test, the Display Test, the Sound Test, the All Lamps portion of the Lamp Test, and the
Solenoid Test.
3.
To halt the Auto Burn-in Mode, switch the game Off and then On.
_all'IlwDIlO~
now starts in the
Attract Mode. (If a switch problem is now reported by the displays, perform the Switch Tests
again to determine the nature of the problem; then, perform necessary repairs.)
SYSTEM-11 B MEMORY CHIP TEST.
A new feature is now included in the Memory Chip Test for System 11B. During power-up, the CPU
performs a self-testing routine. When all tests are satisfactory, the game proceeds to the ~
~,
allowing players to use the game. Whenever a portion of the testing does not produce
satisfactory results, the game displays a message, before proceeding to the next portion of the
testing. ONLY after all tests are satisfactory does the game allow play to begin.
In addition to the displayed message, when any part of the self-test routine fails, LED2
(,DIAGNOSTIC'), mounted on the CPU Board, can be observed to determine the probable cause of
the problem. This LED blinks, or flashes, a certain number of times to identify the probable cause,
as described in the CPU LED Indicator Codes Table. The operator can also start the self-test
routine by pressing the CPU Diagnostic Switch (SW 2) on the edge of the CPU Board.
CPU LED Indicator Codes Table
Diagnostic LED
BlInksl
Display Message
Flashes
1
U25 RAM FAILURE
2
MEM. PROT. FAILURE
3
U51 PIA FAILURE
4 U38 PIA FAILURE
5
U41 PIA FAILURE
6
U42 PIA FAILURE
7 U54 PIA FAILURE
8
U10 PIA FAILURE
9
IROFAILURE
10
U27 ROM FAILURE
11
U26 ROM FAILURE
Explanation
U25 RAM could not be used properly (NO other tests are performed;
the game is locked here, until the game is turned off).
This message means that (A) the Coin Door may be shut; (8) the Mem-
ory Protect Switch may be stuck in the ON position; (C) the memory
protect logic is protecting the memory; or (D) a U25 RAM failure is
occurr ing.(See Note,)
U5' has a malfunction. (See Note 2)
U38 has a malfunction. (See Note 2)
U41 has a malfunction. (See Note 2)
U42 has a malfunction. (See Note 2)
U54 has a malfunction. (See Note 2)
U10 has a malfunction. (See Note 2)
IRO has a malfunction. It may be miSSingor too fast or too slow.
U27's internal checksums do not match. h may be a ROM failure, or its
associated connections and connectingdevices are causing it to ap-
pear to have a problem. (The following U26 test is skipped.)
U26's internal checksums do not match.
Notes: 1. 'Ibis test assumes that the Corn Door is OPEN; it is initiated ONLY by pressing the CPU
Diagnostic Switch (SW2).
2. Altematively, its associated connections or connecting devices are causing the I 'Cto ap-
pear to have problems.
. -;
