(System 11B) ROM Summary
• Pinball Game Assembly Instructions
• Game Play
• Game Status Displays
• Game Adjustment Procedure
• Game Pricing
• Test/Diagnostic Procedures
W[J;)DIJ'OwO[fi)@]
(System 118) ROM Summary
IC
DESCRIPTION TYPE IDENTIFIER BOARD PART NUMBER
Game ROM 1
32Kx8 ROM 27256
U27
CPU A-5343-574-2
Game ROM2
32Kx8 ROM 27256
U26
CPU A-5343-574-1
Sound ROM 1
32Kx8 ROM 27256
U21
CPU A-5343-574-4
Sound ROM 2
32Kx8 ROM 27256
U22
CPU A-5343-574-3
Music/Speech ROM 1 32K x 8 ROM 27256
U4
Audio A-5343-574-5
Music/Speech ROM 2 32K x 8 ROM 27256
U19
Audio A-5343-574-6
Music/Speech ROM 3 32K x 8 ROM 27256
U20
Audio A-5343-574-7
<
N07fIlCIE
To order a replacement ROM from your authorized WILLIAMS ELECTRONICS GAMES
distributor, specify: (1) part number (if available); (2) ROM label color; (3) ROM level (number)
on the label; (4) which game the ROM is used in.
