T.17 Ramp Test
This TEST allows the operator to test the UP/DOWN ramp. The state of the
switch is displayed at the bottom.
The +(plus) and -(minus) buttons change the state of the test.
RAMP UP - Move the ramp to the UP position.
RAMP DOWN - Move the ramp to the DOWN position.
The ENTER button toggles the test.
RUNNING - The ramp will move if necessary.
REPEAT - The appropriate coil will continue to fire regardless of position
STOPPED - The ramp is stationary.
The ESCAPE button exits the test.
T
.18 Reel Test
This TEST allows the operator to test the slot machine. The state of the current
switch is displayed at the bottom. The lamp of the current reel should be on.
The +(plus) and -(minus) buttons change the state of the test.
LEFT REEL - SETS the left reel as current and starts it moving.
CENTER REEL - SETS the center reel as current and starts it moving.
RIGHT REEL - SETS the right reel as current and starts it moving.
STOP TEST - Stops all reels.
ENTER button exits the test if the current state is Stop Test.
ESCAPE button exits the test.
T
.19 Empty Sa lis Test
This test kicks out all balls loaded in troughs, lockups, poppers, and
kickouts until no balls remain in those locations.
Note: As the trough kicks out balls, they will stack up in the shooter groove, which may require
manual clearing in order to allow further balls to be kicked out.
1-18
