8 High Power Driver
p.e.B.
Assembly
A-16116
co
0
0
0
0
0
•
0
0
•
Co.
0
-
..
0
..,
0
0
0
0
J2
0
....•
0
J3
0
0>
1
0
•
000
1
100.0 0 0 0 0 0 0 01
5
1
11
1
J1-1 Violet-White to Solenoid 26, Mini-playfield Right Magnet
J1-2 Violet-White to Solenoid 27, Left Ramp Diverter
J1-3 Not Used
J1-4 Not Used
J1-5 Key
J1-6 Not Used
J1-7 Not Used
J1-8 Blue-Red to Solenoid 26, Mini-playfield Right Magnet
J1-9 Blue-Orange to Solenoid 27, Left Ramp Diverter
J2-1 Black, Ground from J103-3
J2-2 Black, Ground from J1 03-4
J2-3 Violet-Green, from J1 09-5
J2-4 Key
J2-5 Violet-White, from J1 09-7
J3-1 Blue-Green from J125-6
J3-2 Not Used
J3-3 Blue-Violet from J125-8
J3-4 Blue-Brown from J124-1
J3-5 Blue-Red from J124-2
J3-6 Blue-Orange from J124-3
J3-7 Not Used
J3-8 Not Used
J3-9 Key
J3-10 Not Used
J3-11 Not Used
J4-1 Not Used
J4-2 Violet to Solenoid 21, Left Magnet
J4-3 Key
J4-4 Violet to Solenoid 23, Lower Right Magnet
J4-5 Violet to Solenoid 25, Mini-playfield Left Magnet
J4-6 Blue-Violet to Solenoid 23, Lower Right Magnet
J4-7 Blue-Brown to Solenoid 25, Mini-pJayfieJd Left Magnet
J4-8 Blue-Green to Solenoid 21, Left Magnet
J4-9 Not Used
J125
POWER
DRIVER
BOARD
Sol. 21
8 HIGH
POWER
J124
DRIVER
BOARD
Sol. 27
J103
J1
J109
Sol. 26
I
L __________
Twilight Zone 3-14
