FLIPTRONIC II BOARD
A-15472
1100000000°*°0°113
JS02
~
JS~
~
,-I
__
J;_S;_o3_
-l1 ~
10 0*0 01
5
1
J901-1 White-Blue, 50VAC loop fromJ104-1
J901-2 White-Blue, loop from J901-1
J901-3 White-Blue, 50VAC loop, from J1 04-2
J901-4 Key
J901-S White-Blue, loop from J901-3
J902-1 Orange-Gray,
holding to upper left flipper
J902-2 Not Used
J902-3 Black-Blue, power to upper left flipper
J902-4 Orange-Violet, holding to upper right flipper
J902-S Not Used
J902-6 Black-Yellow, power to upper right flipper
J902-7 Orange-Blue, holding to lower left flipper
J902-8 Not Used
J902-9 Blue-Gray, power to lower left flipper
J902-10 Key
J902-11 Orange-Green, holding to lower right flipper
J902-12 Not Used
J902-13 Blue-Violet, power to lower right flipper
J903 Ribbon Cable, data to/from J202; JS06; J601
J904-1 Gray, +5V from J 114-4
J904-2 Gray-Green, +12V from J114-2
J904-3 Key
J904-4 Black, Ground from J114-7
J904-S Black, Ground from J114-S
--
° °
g
* ° °
...,
° °0
~(l)
~-
J900
1\
1°°*° 001100 ° 0*°1
u
6
1 6
1
J90S-1 Blue-Violet, to right flipper opto
J90S-2 Blue-Gray, to left flipper opto
J90S-3 Black-Yellow, to right flipper opto
J90S-4 Key
J90S-5 Black-Blue, to left flipper opto
J90S-6 Orange, Switch Ground
J906-1 Black-Green, to lower right end-ot-stroke switch
J906-2 Key
J906-3 Black-Blue, to lower left end-of-stroke switch
J906-4 Black-Violet, to upper right end-of-stroke switch
J906-5 Black-Gray, to upper left end-of-stroke switch
J906-6 Orange, Switch Ground
J907-1 Blue-Yellow, +SOV to lower right flipper
J907-2 Blue-Yellow, loop from J907-1
J907-3 Key
J907 -4 Gray-Yellow, +SOV to lower left flipper
J907-5 Gray-Yellow, loop from J907-4
J907-6 Blue-Yellow, +SOV to upper right flipper
J907-7 Blue-Yellow, loop from J907-6
J907-8 Gray-Yellow, loop from J907-9
J907 -9 Gray-Yellow, +SOV to upper left flipper
P C, Board Lagend
J1.J6 Coin Door Interface Board
J1xx Power Driver Board
J2xx CPU Board
J5xx Audio Board
J6XX Dot Matrix Controller Board
J9xx Fliptronic II Board
Twilight Zone 3-28
