POWER DRIVER BOARD CONTINUED ...
J133-1 Red-Brown, Row1 to playfield lamps
J133-2 Red-Black, Row2 to playfield lamps
J133-3 Key
J133-4 Red-Orange, Row3 to playfield lamps
J133-5 Red-Yellow, Row4 to playfield lamps
J133-6 Red-Green, Row5 to playfield lamps
J133-7 Red-Blue, Row6 to playfield lamps
J133-8 Red-Violet, Row7to playfield lamps
J133-9 Red-Gray, Row 8 to playfield lamps
J 134 Not Used
J 135-1 Not Used
J135-2 Not Used
J135-3Key
J 135-4 Not Used
J135-5 Not Used
J135-6 Not Used
J 135-7 Not Used
J135-8 Red-Violet, Row 7 to cabinet lamp
J135-9 Red-Gray, Row 8 to cabinet lamp
J136-1 Key
J136-2 Not Used
J136-3 Yellow/Gray, Col8tocabinet
lamp
J137-1 Yellow-Brown, Coli
to playfield lamps
J137-2 Yellow-Red, Col 2 to playfield lamps
J137-3 Yellow-Orange, Col 3 to playfield lamps
J137-4 Yellow-Black, Col 4 to playfield lamps
J137-5 Yellow-Green, Col 5 to playfield lamps
J137-6 Yellow-Blue, Col 6 to playfield lamps
J137-7 Yellow-Violet, Col 7 to playfield lamps
J137-8 Key
J137-9 Yellow-Gray, Col 8 to playfield lamps
J138 Not Used
Twilight Zone 3-34
p,e. Board Legend
J1-J6 Coin Door Interface Board
J1xx Power Driver Board
J2xx CPU Board
J5xx Audio Board
J6xx Dot Matrix Controller Board
J9xx Fllptronic II Board
