POWER DRIVER BOARD CONTINUED ....
J115-1 Yellow-White, 6.8VAC from transformer secondary
J11S-2 White-Brown, 6.8VAC from transformer secondary
J11S-3 White-Brown, loop from J11S-2
J 11S-4 White-Orange, 6.8VAC from transformer secondary
J11S-S White-Yellow, loop from J11S-6
J11S-6 White-Yellow, 6.8VAC from transformer secondary
J11S-7 Orange, 6.8VAC from transformer secondary
J11S-8 Orange, 6.8VAC loop from J11S-7
J11S-9 Key
J11S-10 Green, 6.8VAC from transformer secondary
J11S-11 Brown, 6.8VAC from transformer secondary
J11S-12 Brown, 6.8VAC loop from J11S-11
J116-1 Key
J116-2 Gray-Yellow, +12VDC to coin door; J2-4
J116-3 Black, Ground to coin door; J2-S
J116-4 Not Used
J117-1 Key
J117-2 Gray-Yellow, +12VDC to J606-7
J117-3 Black, Ground to J606-3
J117 -4 Gray, +SVDC to J606-S.
J118-1 Key
J 118-2 Gray-Yellow, +12VDC playtieldlcabinet
J118-3 Black, Ground
J118-4 Not Used
J119-1 White-Violet, 6.8VAC G.I. to coin door; J2-2
J119-2 Key
J119-3 Violet, Return G.!. to coin door; J2-1
J120-1 Not Used
J120-2 Orange, Return G.I. to insert
J120-3 Yellow, Return G.!. to insert
J120-4 Key
J120-5 Green, Return G.I. to insert
J120-6 Not Used
J120-7 Not Used
J120-8 White-Orange, 6.8VAC to insert
J120-9 White-Yellow, 6.8VAC to insert
J120-10 White-Green, 6.8VAC to insert
J120-11 Not Used
J121-1 Brown, Return G.!. to playtield
J121-2 Orange, Return G.I. to playtield
J121-3 Yellow, Return G.I. to playtield
J121-4 Key
J121-S Not Used
J121-6 Violet, Return G.!. to playtield
J121-7 White-Brown, 6.8VAC to playtield
J121-8 White-Orange, 6.8VAC to playtield
J121-9 White-Yellow, 6.8VAC to playfield
J121-10 Not Used
J121-11 White-Violet, 6.8VAC to playtield
,, --
..
J122 Not Used
J123 Not Used
J124-1 Blue-Brown, 80125 to playtield magnet
J124-2 Blue-Red, 80126 to playtield magnet
J124-3 Blue-Orange, 801 27 to playtield coil
J124-4 Key
J124-5 Blue-Yellow, 80128 to playtield flasher
J12S-1 Black-Brown, 80117 to playfield flasher
J12S-2 Black-Red, 80118 to playtield flasher
J12S-3 Black-Orange, 80119 to playfield flasher
J12S-4 Key
J12S-S Black-Yellow, 80120 to playfield flasher
J12S-6 Blue-Green, 80121 to playfield magnet
J12S-7 Not Used
J12S-8 Blue-Violet, 80123 to playtield magnet
J12S-9 Blue-Gray, 80124 to playtield motor
J126 Not Used
J127-1 Brown-Black, 8019 to playtield coil
J127-2 Key
J127-3 Brown-Red, 80110 to playfield coil
J127-4 Brown-Orange, 80111 to playfield coil
J127-S Brown-Yellow, 80112 to playtield coil
J127-6 Brown-Green, 80113 to playfield coil
J127-7 Brown-Blue, 80114 to playfield coil
J127-8 Brown-Violet, 80115 to playfield coil
J127-9 Brown-Gray, 80116 to playfield coil
J128 Not Used
J129 Not Used
J130-1 Violet-Brown, 8011 to playfield coil
J130-2 Violet-Red, 8012 to playtield coil
J130-3 Key
J130-4 Violet-Orange, 8013 to playtield coil
J130-S Violet-Yellow, 8014to playfield coil
J130-6 Violet-Green, 8015 to playfield coil
J130-7 Violet-Blue, 8016 to playfield coil
J130-8 Violet-Black, 8017 to playfield coil
J130-9 Violet-Gray, 8018 to playfield coil
J131 Not Used
J132 Not Used
P.C Board Legend
J1-J6 Coin Door Interface Board
J1xx PowerDriverBoard
J2xx CPU Board
J5xx Audio Board
J6xx Dot MatrixController Board
J9xx FliptronicII Board
Twilight Zone 3-33
